b� Use a tool to remove the screws o the stopper ass as shown
in the below gure and then assemble them to the other side of
the door�
c� Use a tool to remove the axle and two stoppers on the lower
hinge and then assemble them to the position as shown in the
below gure�
3� Assemble the refrigerator door and freezer door to the opposite
side�
1)� a� Remove the adjustable front foot as shown below by hand and
then assemble the lower hinge to the other side of the cabinet
and x the screws by using a tool�
b� Assemble the shorter adjustable front foot to the lower hinge
side and adjust the height of the foot to make the refrigerator
stay in level�
2)� Put on the freezer door and turn the middle hinge by 180
°C
and
then assemble it to the other side of the cabinet; use a tool to
screw up the 3 screws to x the middle hinge�
3)� Put on the refrigerator door and assemble the left upper hinge to
the other side of the cabinet; use a tool to screw up the 4 screws
to x the upper hinge�
After that, connect the door communication line and the cabinet
communication line and then put on the left upper hinge cover
and x it using a screw�
4)� Assemble the hole cover to the other side of the cabinet and use
a tool to screw up the hole cover�
Door disassembly is nished here�
