Saber Compact ATD-80050A - Page 6

ITEM # ORDERING PA RT# PART DESCRIPTION ITEM # ORDERING PA RT# PART DESC RIPT ION
1 PRT80050-01-02 HANDLE SET, P2WER C2RD END 14 PRT80050A-20 LABEL PAPER
2 PRT80 0 50 - 0 3- 04 HA NDL E SET 15 PRT8 005 0- 12 CLEA R TUBE, UPPER
3 PRT80050-05 SWIVEL SHAFT 16 PRT80050-11 PR2TECTING C2VER
4 PRT80050-06 P2SITI2N BL2CK 17 PRT80050A-13 CLEAR TUBE, L2WER
5 PRT80050-07 FIXING RING 18 PRT80050A-17 LED B2ARD
6 PRT80050-16 PRESSURE SPRING 19 PRT80050-30 2N/2FF SWITCH
ASSEMBLY
7 PRT80050-18 BL2CK 20 PRT80050-25 SCREW, ST2.5X10
8 PRT80050-15 PULL R2D 21 PRT80050A-21 SCREW, ST2.9X6
9 PRT80050-19 H22K 22 PRT80050-24 SCREW, ST3X15
10 PRT80050-08-38 ELASTIC BAND ASSEMBLY 23 PRT80050A-23 PLASTIC LABEL
11 PRT80050-26 PIN 24 PRT80050-33 P2WER C2RD
12 PRT80050-27 ELASTIC PIN 25 PRT80050-28 R2UND TERMINA L
13 PRT8 00 50 - 14 INS ERT
ATD-80050A
1
1
2
2
8
15
13
3
5
17
20
18
4
12
11
9
10
7
22
23
14
6
10
19
16
21
24
19
25
