Page 22
PART LIST
Steering Ball Bearing
TC-SCH014RD Steering Post PO-CB0805 Ceramic Ball Bearing 5x8x2.5mm (1pc)
TC-SCHC005 Steering Mount Plate 2.5mm PO-CB1005 Ceramic Ball Bearing 5x10x4mm (1pc)
TC-SCHC006 Steering Plate 3mm PO-CB1510 Ceramic Ball Bearing 15x10x4mm (1pc)
PO-CBST05 Sabre - FD & FD Mini Ceramic Ball Bearing Set (14pcs)
Shock Spring
PS-TR15600
Gamma Spring (14 x 1.5 x 6.00) 344gf/mm, 19.2lb/in Suspension
PS-TR15650
Gamma Spring (14 x 1.5 x 6.50) 306gf/mm, 17.1lb/in 4216R-P4S1 Suspension Mount 3.0 Red
PO-SSU001RD Suspension Mount 1.5 Red
PO-SSU002RD Suspension Mount 2.0 Red
Linkage PO-SSU004RD Wide Height Spacer Set 0.5 & 1.0mm Red (each 4pcs)
MC-MLK001 3mm x 15mm Tie Rod Steel (2pcs) PO-SSU005RD Suspension Mount Separate Red (2pcs)
PA-HBS003 5.3mm Steel Ball (5pcs) PO-SSU009RD Suspension Mount 1.0 Red
Kit TC-PMHS01 Ball Cup 14.5 (8pcs) PO-SSU010RD Height Spacer Set 0.5 & 1.0mm Red
MC-SFDM01 Sabre 10th Scale Front Drive Mini Car Kit TC-PMHS02 Ball Cup 18.5 (4pcs)
TC-PSU005 3mm x 30mm Tie Rod Steel (2pcs)
TC-SLK3100BK 3mm x 100mm Tie Rod Steel (1pc) Shock Absorber
Chassis PO-PSH102 Optional Shock Piston 1.0 x 2 Holes (4pcs)
MC-SCHC003 Mini Car Damper Stay (1pc)
PO-PSH103 Optional Shock Piston 1.0 x 3 Holes (4pcs)
MC-SFCHC01 Sabre FD Mini Main Chassis 2.0mm
Accessores PO-PSH122 Optional Shock Piston 1.2 x 2 Holes (4pcs)
MC-SFCHC02 Sabre FD Mini Top Deck 2.0mm
AW-BW31RD
Small M3 Bevel Washer Red (10pcs)
PO-PSH123 Optional Shock Piston 1.2 x 3 Holes (4pcs)
PA-BMP01RD Battery Mount Post (1pc) PA-AP0001 Aetenna Post (2pcs) PO-PSHT07 Titanium Coated Shock Shaft (2pcs)
PA-BMW001 Battery Mount Wire (2pcs)
PA-AT0001
Antenna Tube (4pcs)
PP-010321
Oil Mixed O-Ring for Dampers 40° (10pcs)
PO-YM0002 Small EVA Bumper PA-BPS3SV Short Body Clip M6 Silver (20pcs)
PP-BMR001 Battery Mount O-Ring (4pcs) PA-ER0020 M2 E-Clip (30pcs)
SK-CH1001 Bumper & Body Post Set PM-OR1004 O-Ring 2x4x1mm (10pcs) Stabilizer
SK-CH1002 Body Post Set
PP-010320
Oil Mixed O-Ring for Dampers 30° (10pcs) 4252R-SET4 Stabilizer Retainer Red (4pcs)
TC-PMPS01 Servo Arm & Mount TC-SLB001
Sabre Decal Sticker
AW-SB01RD Stabilizer Ball Red (4pcs)
TC-SCH007RD Sabre FD Front Bulkhead RH Red MC-SSBS01 Stabilizer Bar Set
TC-SCH008RD Sabre FD Front Bulkhead LH Red MC-SSBSF1 Stabilizer Bar 1.1, 1.3 & 1.5 (each 1pc)
TC-SCH011RD FD Aluminum Front Bulkhead Cover RH & LH Red Shim MC-SSBSR1 Stabilizer Bar 1.1, 1.3 & 1.5 (each 1pc)
TC-SCH012RD Transmission Mount Red PA-100305 3 x 5 x 0.1,0.2,0.3mm Shim (each 10pcs)
TC-SCH013RD Sabre FD Sevro Mount Red (1pc)
PA-100406 4 x 6 x 0.1,0.2,0.3mm Shim (each 10pcs)
TC-SCH015RD Sabre Series Bulkhead Red (1pc) PA-100507 5 x 7 x 0.1,0.2,0.3mm Shim (each 10pcs) Shock Spring
TC-SCH018RD Sabre Series Bulkhead Cover LH & RH Red PA-101012 10 x 12 x 0.1,0.2,0.3mm Shim (each 10pcs)
PS-TR15550
Gamma Spring (14 x 1.5 x 5.50) 393gf/mm, 22.0lb/in
PA-101215 12 x 15 x 0.1,0.2,0.3mm Shim (each 10pcs)
PS-TR15575
Gamma Spring (14 x 1.5 x 5.75) 367gf/mm, 20.5lb/in
PS-TR15625
Gamma Spring (14 x 1.5 x 6.25) 324gf/mm, 18.1lb/in
Drive Train
PS-TR15675
Gamma Spring (14 x 1.5 x 6.75) 289gf/mm, 16.2lb/in
MC-SDT003 FD Mini Gear Shaft Set (each 1pc) Spacer
PS-TF17625
Alpha Spring (13 x 1.7 x 6.25) 626gf/mm, 35.0lb/in
MC-SMAS02 Gear Set AW-M100RD
Ultra Wide 3mm x 1.0t Collar Red (10pcs) PS-TF17650
Alpha Spring (13 x 1.7 x 6.50) 591gf/mm, 33.1lb/in
PA-SDB224 2.4mm Diff. Ball Steel (24pcs) AW-M200RD
Ultra Wide 3mm x 2.0t Collar Red (10pcs) PS-TF17675
Alpha Spring (13 x 1.7 x 6.75) 560gf/mm, 31.3lb/in
PO-DT0008 2 x 25mm Diff. Screw (2pcs) AW-M5050RD 5mm x 0.5t Collar Red (8pcs)
PS-TF17700
Alpha Spring (13 x 1.7 x 7.00) 532gf/mm, 29.8lb/in
PO-DT1001RD Diff. Joint Ring Red (2pcs) AW-M5100RD 5mm x 1.0t Collar Red (8pcs)
PS-TF17725
Alpha Spring (13 x 1.7 x 7.25) 507gf/mm, 28.3lb/in
PO-PTB602 Thrust Bearing (2pcs) AW-M5200RD 5mm x 2.0t Collar Red (8pcs)
PS-TF14575
Beta Spring (13 x 1.4 x 5.75) 347gf/mm, 19.4lb/in
PO-SDT109 Diff. Hub Set AW-S050RD
3mm x 0.5t Collar Red (10pcs) PS-TF14600
Beta Spring (13 x 1.4 x 6.00) 325gf/mm, 18.2lb/in
ZS-506 Diff. Ring (2pcs) AW-S100RD
3mm x 1.0t Collar Red (10pcs) PS-TF14625
Beta Spring (13 x 1.4 x 6.25) 306gf/mm, 17.1lb/in
ZS-508 Diff. Spring AW-S150RD
3mm x 1.5t Collar Red (10pcs) PS-TF14650
Beta Spring (13 x 1.4 x 6.50) 294gf/mm, 16.2lb/in
AW-S200RD
3mm x 2.0t Collar Red (10pcs) PS-TF14675
Beta Spring (13 x 1.4 x 6.75) 274gf/mm, 15.3lb/in
AW-S250RD
3mm x 2.5t Collar Red (10pcs)
Drive Shaft AW-S500RD
3mm x 5.0t Collar Red (10pcs)
PO-DT0011 Anti-Slip Universal Pin (8pcs) Linkage
PO-DT1006RD 6.2mm Hex wheel Adapter Set Red (4sets) PO-MLKS01RD Al. Tie Rod Set Red
PO-MDT004 Steel Universal Bone (1pc) Screw PO-MLK001RD 15mm Al. Tie Rod Red (2pcs)
PO-SDT018 Axle Shaft (1pc) PA-BM0306BK Button Head Screw M3 x 6 (10pcs) PO-PSU004RD 30mm Al. Tie Rod Red (2pcs)
PO-SDT019 Locked Universal Join Set (each 1pc) PA-BM0308BK Button Head Screw M3 x 8 (10pcs) PO-SLK3100RD 100mm Al. Tie Rod Red (1pc)
TC-SDT017BK Axle Shaft (2pcs) PA-BM0310BK Button Head Screw M3 x 10 (10pcs)
PA-BM2506BK Button Head Screw M2.5 x 6 (10pcs)
PA-CM0306BK Countersunk Head Cap Screw M3 x 6 (10pcs) Accessores
Ball Bearing PA-CM0308BK Countersunk Head Cap Screw M3 x 8 (10pcs)
PA-BW0060 Balance Weight 5g & 10g
PA-SB0805 Ball Bearing 5 x 8 x 2.5mm (2pcs) PA-CM0310BK Countersunk Head Cap Screw M3 x 10 (10pcs)
SS-KM01BK Middle Size Sevro Savers
PA-SB0805F Flanged Ball Bearing 5 x 8 x 2.5mm (2pcs)
PA-SB1005 Ball Bearing 5 x 10 x 4mm (8pcs)
PA-SB1510 Ball Bearing 10 x 15 x 4mm (4pcs) Nut Nut
AW-LNF4RD M4 Aluminum Flange Nylon Nut Red (5pcs) AW-FN03RD Aluminum Flat Nut M3 Red (5pcs)
PA-FN00M3 Flat Nut M3 (10pcs) AW-SNF4RD M4 Al.Serrated Wheel Nut Red (4pcs)
Suspension PA-LN00M2 2mm lock nut
4111R-P4S1 Sus. Mount 0 Red
4112-P4S1 Mounting Ball (8pcs) Set Screw
4215R-P4S1 Sus. Mount 2.5 Red Set Screw
PA-SS0303 M3x 3mm Stainless Steel Set Screw (10 pcs)
MC-MSU002 Front Hinge Pin (2pcs) PA-SS0303BK Steel Set Screw M3 x 3 (10pcs)
PA-SS0306 M3x 6mm Stainless Steel Set Screw (10 pcs)
MC-MSU003 Rear Hinge Pin (2pcs) PA-SS0306BK Steel Set Screw M3 x 6 (10pcs)
PA-SS0308 M3x 8mm Stainless Steel Set Screw (10 pcs)
MC-MSU006RD Sus. Mount FR-0 Red PA-SS0308BK Steel Set Screw M3 x 8 (10pcs) PA-SS0310
M3x10mm Stainless Steel Set Screw (8 pcs)
MC-SMSS01 Castor Block - 4 (1pair) PA-SS0310BK Steel Set Screw M3 x 10 (8pcs) PA-SS0312
M3x12mm Stainless Steel Set Screw (8 pcs)
MC-SMTS01 Steering Block & Rear Hub (each 1pc) PA-SS0316BK Steel Set Screw M3 x 16 (8pcs)
MC-SMUS01 F & R Suspension Arm (each 1pc)
MC-SSU007 3 x 41.5mm Sus. Pin (2pcs) Titanium Screw
MC-SSUC002 Front Upright Plate Set (1pc)
TI-SF0306 M3x6 Titanium Button Head Hex Screws (6pcs)
PO-PCH011RD Special Chassis Nuts (3pcs)
TI-SF0308 M3x8 Titanium Button Head Hex Screws (6pcs)
PO-SSU007 3 x 45mm Sus. Pin (2pcs) Drive Train
TI-SF0310 M3x10 Titanium Button Head Hex Screws (6pcs)
TC-PCH016RD Standoff Post Red (2pcs)
PO-CDB212BK 2.4mm Ceramic Diff. Ball (12pcs) TI-SC0306 M3x6 Titanium Countersunk Head Hex Screws (6pcs)
PO-PTB602C Pre-assm. Ceramic Ball Thrust Bearing 2x6mm (1pc) TI-SC0308 M3x8 Titanium Countersunk Head Hex Screws (6pcs)
PO-SDT022 Derlin Spool Cup (2pcs)
TI-SC0310 M3x10 Titanium Countersunk Head Hex Screws (6pcs)
Shock Absorber PO-SDT106RD Aluminium Differential Hop-Up Set (Red)
PO-PSH002 Shock Teflon O-Ring Guide (4pcs) PO-SDT113RD Hybrid Spool Set Red
TC-PMMS02 Shock Parts
TC-PMRS01 Shock Piston Parts
TC-PSH002 Shock Bladder (4pcs) Drive Shaft
TC-PSH007 Shock Shaft (2pcs) AW-WS44RD Wheel Spacer Set Red (each 4pcs)
TC-PSH101RD Shock Body Set Ver.2 (each 1pc) PO-DT1004RD 5.2mm Hex wheel Adapter Set Red (4sets)
TC-PSHS01RD Shock Set Ver.2 (2sets) PO-DT1007RD Al. Axle Pin Holder Red (each 4pcs)
PO-DT1007TI Al. Axle Pin Holder Ti. (each 4pcs)
PO-MDT001TIRD Al. Universal Bone 31mm Ti (1pc)
PO-MDT002TI Al. Universal Shaft Set 31mm Ti (2sets)
SABRE FD OPTIONAL PARTS LIST
SABRE FD Mini STANDARD PARTS LIST
