4. Saga Pro Series Technical Specifications:
Model
SAG6000 SAG6002 SAG6003
Dimensions 2U 2U 3U
8 ohms Stereo Power 2x150W 2x350W 2x500W
4 ohms Stereo Power 2x250W 2x450W 2x800W
8 ohms Bridge Power 500W 900W 1600W
Frequency Response 20Hz to 20KHz < +/-0.5dB
THD <0.05% (1KHz)
Input Impedance 10K ohms
Input Level 0dB
Signal/Noise >95dB
Input insulation >82dB (1KHz)
Power Supply 120 VAC ~ 60Hz
Signal Compressor
NO
YES
Weight 33.07 lbs 41.89 lbs 59.52 lbs
Dimensions 18.9in x 16.5in x 3.469in 18.9in x 18.11in x 5.197in
Packing Dimensions 21.26in x 18.9in x 6.693in 21.26in x 20.87in x 8.268in
5. Saga Pro Series factory typical settings:
a. Power switch position at “O” (OFF)
b. Ch A/B Volume position at "∞" (MIN)
c. Ground/Lift switch position at "┴"
d. Output mode switch position at “STEREO”
6. Notes
a. Please read the entire attached documents carefully before using the device, and retain for future
reference.
b. The power supply must match the demand of the device with reliable ground wire.
c. Make sure the power to the device is OFF before connecting or disconnecting.
d. The device should be located away from high temperature, moisture and powerful electromagnetic field.
e. Only use a dry, soft cloth to clean the device.
