Cleaning the Interior of the Mounting
Medium Tubing
The purpose of this procedure is to clean the interior
of the mounting medium tubing using a solvent, preferably
xylene. Do not use this cleaning function to prime the
mounting medium as the flow rate is too high and will
generate air bubbles in the line
CAUTION: In this mode, the dispensing pump is
operated at the maximum stroke just like during initial
priming. Suction and dispense operations are
performed. Also, do not use this mode for initial
priming of mounting medium because air bubbles will
generate as mounting medium is introduced.
NOTE: This menu item is available only when the system
is on standby or paused or when the system check screen
is displayed.
1. Press the MENU key.
2. Press the < and > keys to highlight 10, “CLEANING,”
and then press the ENTER key.
3. The cleaning screen appears (Figure 3-Q).
4. Place a full bottle containing solvent.
5. Remove the entire dispensing tray from the system
and set the waste tray for initial priming at a position
below the dispensing nozzle.
6. Press the START key to start cleaning.
7. To cancel dispensing of solvent, press the STOP key
(Figure 3-R). Once the dispensing stops, the display
returns to the menu screen.
8. Remove the waste tray for initial priming and set the
original dispensing tray again.
9. To return to the menu screen, press the EXIT key.
Figure 3-Q: Cleaning Screen
Figure 3-R: Cleaning in Progress Screen
Viewing the Software Version
View the software version using this function.
NOTE: This menu item is available only when the system
is on standby or paused or when the system check screen
is displayed.
1. Press the MENU key.
2. Press the < and > keys to highlight 11, “SOFTWARE
VERSION,” and then press the ENTER key.
3. The software version screen appears (Figure 3-S).
4. To return to the menu screen, press the EXIT key.
Figure 3-S: Software Version Screen
<CLEANING>
Set a container
[START] to start
<CLEANING>
In process
10
[STOP] to stop
MAIN:N94-900-00
SUB1:N94-910-00
SUB2:N94-920-00
SUB3:N94-930-00
