SALICE F70 - Drawer Drilling Procedures; Rear Hook Drilling

LN - 10
ø 6x10
7
40 mm MIN
*
95 mm MIN
11
LN - 10
ø 6x10
7
40 mm MIN
*
11
A
11
ø
6
x 10
13 MAX
7
LN - 10
ø 6x10
7
40 mm MIN
*
95 mm MIN
11
LN - 10
ø 6x10
7
40 mm MIN
*
11
A
A
A
A
REAR HOOK
Use SGD704UGXA drilling template for rear hook,
see page 35.
3-SIDED drawer
4-SIDED drawer
Synchroniser for Push runners, see page 32.
Lever for the tilt adjustment, see page 37.
Drawer drilling
40 mm MIN
75 mm MIN
with Synchroniser
for Push runners
or with Lever for the
tilt adjustment
