SALICE F70 - F70 Smove Full-Extension Runner; Product Features; Technical Dimensions

16 MAX
21
13 MAX 6 MIN
38
12
26
9.528.5
21
(X - 42)
0
-1.5
(X)Larghezza interna mobile
MAX 16
21
13
1226
9.528.5
21
(X - 42)
0
-1.5
Larghezza cassetto
Luce massima superiore 6
Altezza cassetto = Altezza apertura - 21
Altezza apertura
Per spessore cassetto pari a
Sottrarre dalla larghezza interna del mobile
16 mm 15 mm 14 mm 13 mm 12 mm
10 mm 12 mm 14 mm 16 mm 18 mm
Luce sotto il cassetto
Larghezza cassetto:
38
SMOVE: FULLY INTEGRATED IN THE RUNNER, DECELERATES THE CLOSING ACTION
OF THE DRAWER
Product features:
- Full-extension with synchronised movement of the sliding elements to guarantee lateral
stability and a perfectly silent sliding movement
- Available in the full range of lengths from 350 mm in 50 mm increments to 750 mm
- SMOVE decelerated closing with 50 mm stroke
- Clip with pressed steel elements to fix the runner to the drawer
- Tool free sideways adjustment +/- 1.5 mm, integrated into the clip
- Tool free depth adjustment +/- 3 mm, integrated into the clip; through the oval slot on
the runner it is possible to obtain a further depth adjustment of +/- 4.5 mm
- Tool free height adjustment + 2.5 mm, integrated into the clip; through the oval slot on
the runner it is possible to obtain a further height adjustment of +/- 6 mm
- Tool free tilt adjustment + 3 mm (optional, when the optional lever is fitted)
- Max. drawer side thickness: 16 mm
- Compatible with Lineabox drawers
- Finish: bright zinc-plated
F70 Smove - Full-extension runner
Dimensions
(X) Internal width of the cabinet
24
