SALICE Progressa - Page 11

8
Y1 = Min. 50
X
2
Y2 = Min. 40
300
Y1 = Min. 50
28.5
Y1 = Min. 50 Y1 = Min. 50
Y2 = Min. 40
Y2 = Min. 40
Plan view - Full-extension
Technical information
Dimensions
With larger shelves, it is possible to increase the number of runners in order to improve the load capacity and the stability.
For Progressa
+
Shelf runners
RUNNER LENGTH
(LN)
X
350 mm 305 mm
400 mm 305 mm
450 mm 320 mm
500 mm 382.5 mm
11
