1
2
1
2
Rotate the lever to adjust.
Drawer back preparation, see page 10.
AGLRXX3F
tilt adjustment lever, see page 70.
Assembly of tilt adjustment levers (optional)
Tilt adjustment + 3 mm
Open the drawer (1) and press the lever towards the back of the
cabinet (2) to achieve the adjustment.
Maximum 3 mm rise of drawer back (tool free).
Pull out the drawer and remove the plastic insert, both right and left. Insert the tilt adjustment levers AGLRXX3F, both right and left.
For all Progressa and Progressa
+
runners
27
