SALICE Progressa - Page 30

16 MAX
21
13 MAX 6 MIN
38
12
26
9.528.5
21
(X - 42)
0
-1.5
SMOVE: SOFT CLOSE MECHANISM FULLY INTEGRATED INTO THE DRAWER RUNNER
Product features
- 45 Kg Dynamic load capacity
- Available in lengths ranging from 350 mm to 550 mm in 50 mm increments
- Full extension with a synchronized mechanism
- Enhanced smooth soft closing action
- Elongated holes for depth and height adjustment
- Adjustable clips allow for easy drawer insertion and removal
- Tool free height adjustments + 2.5 mm
- Tool free depth adjustments +/- 3 mm
- Tool free side adjustments +/- 1.5 mm
- Optional tool free tilt adjustment +3 mm
- 13 mm to 16 mm drawer material thickness
- Compatible with Lineabox Easy drawers
- Finish: bright zinc-plated
- 100% Made in Italy
Progressa - Full extension runner for 13 mm to 16 mm drawer material thickness
Smove
Dimensions
(X) Internal width of the cabinet
30
