Drilling templates for drawers - For all Progressa, Progressa
+
and Progressa
+
Shelf runners
Back drilling for hook
Pre-drilling for the clips reduces the possibility of splitting the wood, thus assuring the correct and level installation of the clips.
The correct and level mounting assures a smooth assembly and operation of the drawer runner.
Technical information, see page 10.
Use a ø 6 mm drill bit
Pre-bore for rear hook for proper alignment and depth (min. depth = 10 mm)
Drilling template
ASGD704U3XA
PACKING
1 box = 1 pc.
Front locking device
AFCGXX3B
Right and left
65
