AGAPXXYI
For shelves that are less
than 12 mm thick, the
runner can be used
together with the rear
hook bracket, thus
eliminating the need
for the rear hole in
the shelf.
PACKING:
1 box = 100 pcs.
Rear hook bracket
Assembly instructions
1 A) Fix the bracket, aligned with the back of the shelf.
2) Fix the magnet to the bottom.
1 B) Fix the bracket to the shelf with the rear hook support.
The bracket needs to be aligned to the rear hook support.
3) The shelf is held at the maximum opening position.
AROSXXY
The shelf is held at the maximum opening position
by means of a rear-xed bracket and a magnet.
PACKING
1 box = 20 magnets, 20 brackets.
Screws included.
Rear-fixed bracket and magnet - Lock-open function for runners and drawers
Accessories - For Progressa
+
Shelf runners
