WARNING To prevent possible risk of infection from
contaminated medication, cleaning of the nebulizer is
recommended after each treatment.
NOTE The nebulizer kit is for single patient use only.
NOTE Please follow national requirements to dispose the unit
properly.
6. Storage
Keep the unit and accessories dry. Avoid direct sunshine. See
specifications in Section 10 for appropriate environmental storage
conditions.
7. Maintenance
7.1 General Information
1. This unit is oil-less. Do Not Lubricate.
2. Risk of electric shock. Do not disassemble the main unit.
7.2 Filter Change
NOTE Inspect the filter once every month and
replace as necessary or when filter turns gray.
Please follow the below instructions as right
figures.
1. Open the filter cap.
2. Inspect the filter and if dirty, remove filter
with a small, pointed object. Discard the
filter.
3. Replace with a clean filter. Additional filters
should be purchased from your provider.
4. Put the filter cap back.
CAUTION Do not use cotton or any other material as a filter. Do not
wash or reuse the filter. Do not operate the unit without a filter.
7.3 Service
Except for the above instructed user maintenance, all device
servicing must be performed by a Salter Labs
®
authorized service
representative. There are no serviceable parts inside the unit.
Contact your Salter Labs dealer or authorized service center if your
unit needs repair.
WARNING Do not tamper with or attempt to repair the device.
Refer servicing to qualified service personnel.
8. Expected Service Life
The products are intended to offer safe and reliable operation when
used or installed according to the instructions provided by Salter
Labs. Salter Labs recommends that the system be inspected and
serviced by authorized technicians if there are any signs of wear or
concerns with device function and indication on products.
Otherwise, service and inspection of the devices generally should
not be required.
9. Troubleshooting
If your Salter AIRE Elite Compressor fails to function, consult the
Troubleshooting guide below. If the problem persists, consult your
equipment provider.
Problem Cause and Solution
‧
Check if plug is properly fit into an appropriate
electrical outlet.
‧When device has been run continuously for over
30 minutes right before using, an auto shut down
may activate by built-in thermal protector, cool
down device for 30 minutes before next usage.
‧
Check for proper electrical voltage.
‧
Check tubing for blockage or air leakage at
connection to Salter AIRE Elite Compressor or
nebulizer cup, replace as needed.
‧Check the nebulizer cup if it is properly assembled
and not damaged. If there is any damage, replace
‧
Check if filter is too dirty, replace as needed.
10. Specifications
(All specifications are subject to change without notice.)
(Note: Refer to the rating
120VAC,60Hz,1.2A
( For 120V System)
230VAC,50Hz,0.6A
( For 230V System)
Maximum Compressor
Pressure
Classification
Class II.
BF equipment.
IP2X
No AP/APG protection.
Applied part
Dimensions (W x D x H)
14.6 × 20.3 × 9.5 cm /
5.7” × 7.9” × 3.7”
Weight (approx.)
Fuse (non-user serviceable)
Warranty
Environment
Temperature
Operation: 10℃ to 40℃/ 50℉ to 104℉
Storage: -15℃ to 50℃ / 5℉ to 122℉
Transport: -15℃ to 70℃/ 5℉ to 158℉
Humidity
Operation: 10% to 90%RH non-condensing
Storage: 10% to 90%RH non-condensing
Transport: 10% to 90% RH non-condensing
11. Accessories
Model Description
8501-1-2 Salter AIRE Elite Replacement filters
8258-0-1 Compressor Carrying bag
8660 NebuTech® Nebulizer – Reusable
8960 NebuTech Nebulizer – Disposable
8967 NebuTech Nebulizer with Pediatric Mask
8984 NebuTech Nebulizer with Adult Mask
8900 Nebulizer with Tee Adapter
8906 Nebulizer with Pediatric Mask
8924 Nebulizer with Adult Mask
12. Appendix A: EMC Information
Guidance and Manufacturer’s Declaration- Electromagnetic Emissions:
This device is intended for use in the electromagnetic environment
specified below. The user of this device should make sure it is used
in such an environment.
Emissions
Test
Compliance Electromagnetic Environment-Guidance
The device uses RF energy only for its internal
function. Therefore, its RF emissions are very
low and are not likely to cause any
interference in nearby electronic equipment
The device is suitable for use in all
establishments, including domestic
establishments and those directly connected
to the public low-voltage power supply
network.
Harmonic
emissions
IEC61000-3-2
Flicker
Complies
Guidance and Manufacturer’s Declaration- Electromagnetic Immunity:
This device is intended for use in the electromagnetic environment
specified below. The user of this device should make sure it is used
in such an environment.
Immunity Test
IEC60601
test level
Compliance
Electromagnetic
Environment-Gui da nce
Electrostatic
Discharge (ESD)
IEC61000-4-2
±6kV contact
±8kV air
±6kV contact
±8kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30%.
transient/ burst
±2kV for power
supply line
±1kV for
input/out line
line
Mains power quality
should be that of a typical
commercial or hospital
environment.
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
± 1 kV line(s)
to
line(s)
Mains power quality
should be that of a typical
commercial or hospital
environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC61000-4-11
T
0,5 cycle
40 % U
T
dip in U
T
)
for 5 c yc les
70 % U
T
dip in U
T
)
for 25 cycles
<5 % U
T
(>95
% dip in U
T
) for
5 sec
T
for 0,5 cycle
40 % U
T
% dip in U
T
for 5 cycles
70 % U
T
% dip in U
T
for 25 cycles
<5 % U
T
(>95
% dip in U
T
)
for 5 sec
Mains power quality
should be that of a typical
commercial or hospital
environment. If the user of
this device requires
continued operation
during power mains
interruptions, it is
recommended that the
device be powered from
an uninterruptible power
supply or a battery.
(50/60Hz)
magnetic field
IEC61000-4-8
3 A/m 3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE: U
T
is the AC mains voltage prior to the application of the test level
Recommended separation distances between portable and
mobile RF communications equipment and this device:
This device is intended for use in an electromagnetic environment
in which radiated RF disturbances are controlled. The customer or
the user of this device can help prevent electromagnetic
interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and this
device as recommended below, according to the maximum output
power of the communications equipment
Rated
output
power
Separation distance according to frequency of transmitter (
150 kHz to 80 MHz
80 MHz to 800 MHz
800 MHz to 2,5 GHz
For transmitters rated at a maximum output power not listed above, the
recommended separation distance
d
in meters (m) can be estimated using
the equation applicable to the frequency of the transmitter, where P is the
maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures, objects,
and people.
Guidance and Manufacturer’s Declaration - Electromag netic Immuni ty:
This device is intended for use in the electromagnetic environment
specified below. The user of this device should make sure it is used
in such an environment.
Immunity
Test
IEC60601 test
leve l
Compliance Electromagnetic
Environment-Gui da nce
Conducted
RF
IEC
61000-4-6
Radiated
RF
IEC
61000-4-3
3Vrms150 kHz
to 80 MHz
o u ts i de I S M
ban ds
a
3 V/m 80
MHz to 2.5 GHz
3 Vrms
3 V/m
Porta b le a n d mo b i le R F
communications equipment
should be used no closer to any
part of this device, including
cables, than there commended
separation distance calculated
from the equation applicable to the
frequency of the transmitter.
Recommended separation distance
150kHz to 80MHz
150kHz to 80MHz
80 MHz to 2.5G MHz
Where P is the maximum output
power rating of the transmitter in
watts (W) according to the
transmitter manufacturer and d is
the recommended separation
distance in meters (m).
b
Field strengths from fixed RF
transmitters, as determined by an
electromagnetic site survey
c
,
should be less than the compliance
level in each frequency range
d
.
Interference may occur in the
vicinity of equipment marked with
the following symbol:
NOTE 1:
At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2:
These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures, objects
and people.
The ISM (industrial, scientific and medical) bands between 150 kHz and
80 MHz are 6,765 MHz to 6,795 MHz;13,553 MHz to 13,567 MHz; 26,957
MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz.
b/ The compliance levels in the ISM frequency bands between 150 kHz and
80 MHz and in the frequency range 80 MHz to 2.5 GHz are intended to
decrease the likelihood that mobile/portable communications equipment
could cause interference if it is inadvertently brought into patient areas. For
this reason, an additional factor of 10/3 is used in calculating the
recommended separation distance for transmitters in these frequency
ranges.
c/ Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio, AM
and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the device is used exceeds
the applicable RF compliance level above, the device should be observed to
verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the device.
d/ Over the frequency range 150 kHz to 80 MHz, field strengths should be
less than 3 V/m.
100 W. Sycamore Rd.
Arvin, CA 93203 USA
Tel: 661-854-3166
800-421-0024 (in CA)
800-235-4203 (outside CA)
Fax: 661-854-3850
800-628-4690 (US & Canada)
Internet: www.salterlabs.com
Authorized Representative in the E.U.:
MT Promedt Consulting GmbH
Altenhofstrasse 80
D-66386 St. Ingbert, Germany
NOTE Consult distributor(s) or EU representative(s) for
additional technical documents.
800987 Rev D (Side 2) 666001-6720 V1.0
