Samson 373 Series Operating Instructions

32 EB 8389 EN
Statistical information
Dening parameters
1. Select 'Permanent' (Selection).
2. Enter scan rate.
3. Start data logger.
The 'Test information' status indicates
'Test active'.
1.
Diagnosis > Statistical information > Data
logger
− Selection: [Permanent]
2. − Scan rate: 0.2 to 3600.0 s, [1.0 s]
3. − Start data logger
Right-click 'Stop data logger' and select ‘Ex-
ecute’ to stop the data logger ('Test informa-
tion' = 'Test not active').
4.2.2 Triggered data logging
Measured values are saved in a circular buf-
fer after the event dened in 'Start trigger
via' has occurred (see section4.2.2.1 to sec-
tion4.2.2.7). The event that has triggered
data logging is recorded. Data logging is
terminated after 100 measured values per
measured variable have been saved in the
circular buffer. The 'Scan rate' determines
the time between recordings. A 'Pre-trigger
time' greater than 0 also leads to the mea-
suring values before the triggering event for
the time selected being included in the 100
measured values per measured variable. The
'Pre-trigger time' may include the value 100
x 'Scan rate' at the maximum.
Dening parameters
1. Select 'Trigger' (Selection).
2. Select the triggering event.
3. Enter scan rate.
4. Start data logger.
The 'Test information' status indicates
'Test active'. When the data logging is
nished, the Progress bar indicates
'Memory full, data recording completed'.
Right-click 'Stop data logger' and select ‘Ex-
ecute’ to stop the data logger ('Test informa-
tion' = 'Test not active').
4.2.2.1 Triggered by condensed
state
3730-2 3730-3 3731-3 3730-4 3730-5 3731-5
• • • •
1)
1)
Function available in rmware 1.5x and lower
The measured values are included in the trig-
gered data logging when the condensed
state dened in 'Start trigger via condensed
state' arises.
1.
Diagnosis > Statistical information > Data
logger
− Selection: Trigger
2. − Trigger status:
Start trigger via condensed state
− Pre-trigger time:
0.0s to 100 x 'Scan rate', [0.0s]
Note
Note
