When connecting a speaker, be careful that the grooves of the monitor and the speaker .
( )are aligned with each other.
djust the aligned positions until you hear a ‘click’. If a speaker is connected correctly,
you can hear a ‘click’.If a speaker is connected without you hearing a ‘click’, the holding
part may become damaged.
If you need to separate, please pull ( ) a little and push to the right.
MIC / SPK
Connect the red cable of the cables provided when the speaker was purchased to the audio
output terminal at the back of the computer.
Connect the other end of the cable to the red terminal at the back of the speaker.
Connect the light green cable of the cables provided when purchasing the speaker to the
UDIO OUT.
Connect the other end of the cable to the light green terminal at the back of the speaker.
/
Connect a headphone to the black terminal at the right of the speaker.
To Next Page
