Samsung AM018FN4DCH/AA User Manual

Product Specifications
Samsung Electronics 2-3
Indoor Unit(cont.)
Q Mini 4WAY cassette
Model
Small
AM009FNNDCH/AA AM012FNNDCH/AA AM018FNNDCH/AA
AM020FNNDCH/AA
Power Supply ø, #, V, Hz 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60 1,2,208-230,60
Mode
-
HP/HR HP/HR HP/HR HP/HR
Performance
Capacity
(Nominal)
Cooling 2)
kW
- ---
Btu/h 9,500 12,000 18,000 20,000
Heating 2)
kW
- ---
Btu/h 10,500 13,500 20,000 23,000
Condensate
(with high fan speed)
Liter/h
- ---
Power
Power Input
(Nominal)
Cooling 1) W
24 28 36 38
Heating 2) - 24 28 36 38
Current Input
(Nominal)
Cooling 1) A
0.17 0.19 0.27 0.3
Heating 2) - 0.17 0.19 0.27 0.3
Fan
Type -
Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model -
FMC6531SSJ FMC6531SSJ FMC6531SSJ FMC6531SSJ
Type - BLDC BLDC BLDC BLDC
Output x n W 65 x 1 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L CMM 10.00 / 8.50 / 7.50 10.50 / 9.50 / 8.00 13.00 / 11.00 / 9.50 13.50 / 12.00 / 10.20
External Pressure
Min / Std / Max Pa
- ---
-WG - ---
Sound
Sound Pressure High / Mid / Low dBA
34.0 / 30.0 / 26.0 36.0 / 34.0 / 31.0 40.0 / 37.0 / 34.0 41.0 / 37.0 / 34.0
Sound Power High / Mid / Low - - ---
Refrigerant
Type -
R-410A R-410A R-410A R-410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED EEV INCLUDED
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid Pipe (Flare)
ø,mm
6.35 6.35 6.35 6.35
ø, inch 1/4 1/4 1/4 1/4
Gas Pipe (Flare)
ø,mm
12.7 12.7 12.7 12.7
ø, inch 1/2 1/2 1/2 1/2
Drain Pipe (Quick lock) ø,mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Dimensions
Net Weight
kg
12 12 12 12
lbs 26.5 26.5 26.5 26.5
Shipping Weight
kg
14 14 14 14
lbs 30.9 30.9 30.9 30.9
Net Dimensions (W×H×D)
mm
575 x 250 x 575 575 x 250 x 575 575 x 250 x 575 575 x 250 x 575
inch 22.6 x 9.8 x 22.6 22.6 x 9.8 x 22.6 22.6 x 9.8 x 22.6 22.6 x 9.8 x 22.6
Shipping Dimensions (W×H×D)
mm
623 x 298 x 653 623 x 298 x 653 623 x 298 x 653 623 x 298 x 653
inch 24.5 x 11.7 x 25.7 24.5 x 11.7 x 25.7 24.5 x 11.7 x 25.7 24.5 x 11.7 x 25.7
Panel Size
Panel model -
PC4SUSMAN PC4SUSMAN PC4SUSMAN PC4SUSMAN
Panel Net Weight
kg
2.7 2.7 2.7 2.7
lbs 6666
Shipping Weight
kg
4.2 4.2 4.2 4.2
lbs 9.3 9.3 9.3 9.3
Net Dimensions (W×H×D)
mm
670 x 45 x 670 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670
inches 26.4 x 1.8 x 26.4 26.4 x 1.8 x 26.4 26.4 x 1.8 x 26.4 26.4 x 1.8 x 26.4
Shipping Dimensions (W×H×D)
mm
714 x 106 x 724 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724
inch 28.1 x 4.2 x 28.5 28.1 x 4.2 x 28.5 28.1 x 4.2 x 28.5 28.1 x 4.2 x 28.5
Functions
Auto restart -
OOOO
Auto swing - OOOO
Group/individual control - OOOO
External contact control - OOOO
Trouble shooting by LED - OOOO

Samsung AM018FN4DCH/AA Specifications

General

Brand	Samsung
Model	AM018FN4DCH/AA
Category	Air Conditioner
Language	English
