Exploded Views and Parts List
Part List
5-2
NO Code NO Description SPEC
Q’TY SA/
SNA
AQ09NSAN AQ09NSBN AQ09FDN
1 DB94-00454J ASSY BACK BODY ASSY 1 1 1 SA
1-1 DB61-01632D BODY BACK HIPS 1 1 1 SA
1-2 DB69-00834A CUSHION-BODY BACK EPS 1 1 1 SNA
2 DB96-08657A ASSY EVAP MAIN ASSY 1 1 1 SNA
2-1 DB63-00850A COVER-BEARING ABS 1 1 1 SNA
2-2 DB96-09756A ASSY TUBE EVAP IN ASSY 1 1 1 SNA
2-3 DB96-06899A ASSY TUBE EVAP OUT ASSY 1 1 1 SA
3 DB94-00457J ASSY TRAY DRAIN ASSY 1 1 1 SA
3-1 DB63-00848A TRAY DRAIN ABS 1 1 1 SNA
3-2 DB61-01635C BLADE-H HIPS 1 1 1 SA
3-3 DB61-01636A BLADE-V PP 2 2 2 SA
3-4 DB63-00849A TRAY-STABILIZER ABS 1 1 1 SNA
3-5 DB69-00839A CUSHION-TRAY RH EPS 1 1 1 SNA
3-6 DB73-00180A RUBBER-CAP DRAIN GUM-EPM 1 1 1 SNA
3-7 DB31-00371A MOTOR STEP GSP-24RW-046 1 1 1 SA
3-8 DB94-00458B ASSY DRAIN-HOSE ASSY 1 1 1 SA
4 DB93-05732L ASSY -CONTROL IN ASSY 1 1 1 SA
5 DB92-01237A ASSY PANEL FRONT ASSY 1 1 1 SA
DB92-00853F - - 1
5-1 DB64-00989E PANEL FRONT HIPS 1 1 1 SA
5-2 DB92-01207A ASSY GRILLE AIR INLET ASSY 1 1 - SA
DB92-00848F - - 1
5-3 DB90-03094A ASSY COVER-DISPLAY ASSY 1 1 1 SA
5-4 DB63-01591A GUARD-AIR FILTER PP 2 2 2 SA
6 DB97-02851B ASSY-PLATE HANGER SGCC,T0.6 1 1 1 SNA
7 DB61-01638B HOLDER-PIPE HIPS 1 1 1 SA
8 DB63-00844D COVER-TERMINAL HIPS 1 1 1 SA
9 DB93-03170Z ASSY REMOCON HP 1 1 1 SA
10 DB96-03149B ASSY EVAP-SUPPORT RH HIPS 1 1 1 SA
11 DB31-00219A MOTOR FAN 50/60Hz 1 1 1 SA
12 DB94-00456A ASSY-CROSS FAN ASSY 1 1 1 SA
13 DB97-02075A ASSY-BOLT SPECIAL - 1 1 1 SNA
14 DB94-00455A ASSY BEARING-RUBBER ASSY 1 1 1 SA
15 DB94-40007A ASSY BEARING - 1 1 1 SNA
AQ09NSAN/AQ09NSBN/AQ09FDN
