Exploded Views and Parts List
 Part List
 DB93-04193P
No. Code No. Description Specification Q’TY SA/SNA
1 6501-000123 CABLE TIE DACT-140,-,W3.6,L146,NTR,NYLON66 2 SNA
2 DB32-00020E THERMISTOR-WIRE
ASSY
103AT,-,-,-20~+100,-,-,-,-,SSEC 1 SA
3 DB39-01165C CONNECT WIRE WW2-P/J,#1015 16 AWG,-,1P,-,BLU,-,175022-1
(AMP),175057-1 (AMP),TP,220V/50Hz,4mm,120mm,-,-
,TUBE?SSEC
1 SNA
4 DB61-01980A HOLDER-WIRE CLAMP AQT24W6WE,ABS,2.0,-,-,BLACK,- 1 SA
5 DB61-02893A CASE CONTROL-IN WW2,ABS(V0),2.0,179,269,BLACK,SSEC 1 SA
6 DB63-00851A COVER-DRAIN SS-PJT,ABS,-,-,-,-,-,NO,SSEC 1 SNA
7 DB65-00105H TERMINAL BLOCK-
TERMINAL
WW1,JXW,4PIN,4mm,36.4*47,BLK,600V,30A 1 SNA
8 DB68-02809A LABEL BAR CODE -,-,-,-,W170,L115,-,-,-,FOR PACKING CASE 1 SNA
9 DB91-00309A ASSY-SCREW TAPPING WW-INV,M3*20,PH,+,ZPC(YEL) 1 SNA
10 DB39-01165C ASSY POWER CORD HO5VV-F,-,250V 20A,2,000 ? 20,-,-,-,Gray,-
,3G*2.5,WW2,SSEC
1 SA
11 DB93-04128A ASSY PCB-POWER WW2-P/J?H/P?1-STEP,POWER,SSEC 1 SA
12 DB93-04181A ASSY PCB MAIN WW2-P/J,EXP,MAIN ,SSEC 1 SA
13 DB97-02418A ASSY-SCREW TAPPING SS-P/J,TH,M4*L14 3 SA
 DB93-04193D
No. Code No. Description Specification Q’TY SA/SNA
1 6501-000123 CABLE TIE DACT-140,-,W3.6,L146,NTR,NYLON66 2 SNA
2 DB32-00020E THERMISTOR-WIRE
ASSY
103AT,-,-,-20~+100,-,-,-,-,SSEC 1 SA
3 DB39-01165E CONNECT WIRE WW2-P/J,#1015 16 AWG,-,1P,-,BLU,-,175022-1
(AMP),175057-1 (AMP),TP,220V/50Hz,4mm,120mm,-,-
,TUBE?SSEC
1 SNA
4 DB61-01980A HOLDER-WIRE CLAMP AQT24W6WE,ABS,2.0,-,-,BLACK,- 1 SA
5 DB61-02893A CASE CONTROL-IN WW2,ABS(V0),2.0,179,269,BLACK,SSEC 1 SA
6 DB63-00851A COVER-DRAIN SS-PJT,ABS,-,-,-,-,-,NO,SSEC 1 SNA
7 DB65-00061F TERMINAL BLOCK C/O,2P,N(1),1,2TAB,2-
SCREW,300V,20A,36.4*24.2,BLACK,N(1),1
1 SNA
8 DB68-02809A LABEL BAR CODE -,-,-,-,W170,L115,-,-,-,FOR PACKING CASE 1 SNA
9 DB91-00309A ASSY-SCREW TAPPING WW-INV,M3*20,PH,+,ZPC(YEL) 1 SNA
10 DB93-01638D ASSY POWER CORD HO5VV-F,-,250V 20A,2,000 ? 20,-,-,-,Gray,-
,3G*2.5,WW2,SSEC
1 SA
11 DB93-04128D ASSY PCB-PAWER
FORTE
WW2-P/J?C/O?0-STEP,POWER,SSEC 1 SA
12 DB93-04181A ASSY PCB MAIN WW2-P/J,EXP,MAIN ,SSEC 1 SA
13 DB97-02418A ASSY-SCREW TAPPING SS-P/J,TH,M4*L14 3 SA
5-14
