127
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, WB)
14 16 18 19 20 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 5000 125%
10 3.53 0.66 4.99 0.68 5.08 0.69 5.14 0.70 5.20 0.71 5.35 0.72 5.52 0.74
12 3.53 0.68 4.85 0.69 4.95 0.71 5.01 0.72 5.08 0.73 5.23 0.74 5.41 0.75
14 3.53 0.69 4.72 0.71 4.83 0.73 4.89 0.73 4.96 0.74 5.12 0.76 5.31 0.77
16 3.53 0.71 4.60 0.73 4.71 0.74 4.78 0.75 4.85 0.76 5.02 0.77 5.21 0.79
18 3.53 0.73 4.48 0.75 4.60 0.76 4.67 0.77 4.75 0.78 4.92 0.79 5.12 0.81
20 3.53 0.75 4.36 0.76 4.49 0.78 4.57 0.79 4.65 0.80 4.83 0.81 5.03 0.82
21 3.53 0.76 4.31 0.77 4.44 0.79 4.52 0.80 4.60 0.81 4.78 0.82 4.99 0.83
23 3.53 0.78 4.20 0.79 4.34 0.81 4.42 0.82 4.51 0.82 4.70 0.84 4.91 0.85
25 3.53 0.80 4.10 0.81 4.25 0.83 4.33 0.84 4.42 0.84 4.62 0.86 4.84 0.87
27 3.53 0.82 4.01 0.83 4.16 0.85 4.25 0.86 4.34 0.86 4.55 0.88 4.78 0.89
29 3.53 0.84 3.92 0.85 4.08 0.87 4.17 0.88 4.27 0.88 4.48 0.90 4.72 0.91
31 3.53 0.86 3.84 0.88 4.01 0.89 4.10 0.90 4.20 0.91 4.42 0.92 4.66 0.93
33 3.53 0.88 3.76 0.90 3.94 0.91 4.03 0.92 4.13 0.93 4.36 0.94 4.61 0.96
35 3.53 0.90 3.69 0.92 3.87 0.93 4.00 0.94 4.08 0.95 4.31 0.96 4.57 0.98
37 3.53 0.93 3.62 0.94 3.81 0.96 3.91 0.96 4.02 0.97 4.26 0.99 4.53 1.00
39 3.53 0.95 3.56 0.97 3.76 0.98 3.86 0.99 3.98 1.00 4.22 1.01 4.49 1.02
42 3.53 0.99 3.48 1.00 3.69 1.02 3.80 1.02 3.92 1.03 4.17 1.05 4.46 1.06
44 3.53 1.01 3.44 1.03 3.65 1.04 3.76 1.05 3.89 1.06 4.15 1.07 4.44 1.08
46 3.53 1.04 3.39 1.05 3.61 1.07 3.73 1.07 3.86 1.08 4.13 1.09 4.42 1.11
2500 3500 6000 150%
10 3.53 0.67 4.99 0.68 5.08 0.70 5.14 0.71 5.20 0.72 5.35 0.73 5.52 0.75
12 3.53 0.68 4.85 0.70 4.95 0.72 5.01 0.73 5.08 0.73 5.23 0.75 5.41 0.76
14 3.53 0.70 4.72 0.72 4.83 0.73 4.89 0.74 4.96 0.75 5.12 0.77 5.31 0.78
16 3.53 0.72 4.60 0.74 4.71 0.75 4.78 0.76 4.85 0.77 5.02 0.78 5.21 0.80
18 3.53 0.74 4.48 0.75 4.60 0.77 4.67 0.78 4.75 0.79
4.92 0.80 5.12 0.81
20 3.53 0.76 4.36 0.77 4.49 0.79 4.57 0.80 4.65 0.80 4.83 0.82 5.03 0.83
21 3.53 0.77 4.31 0.78 4.44 0.80 4.52 0.81 4.60 0.81 4.78 0.83 4.99 0.84
23 3.53 0.79 4.20 0.80 4.34 0.82 4.42 0.83 4.51 0.83 4.70 0.85 4.91 0.86
25 3.53 0.81 4.10 0.82 4.25 0.84 4.33 0.85 4.42 0.85 4.62 0.87 4.84 0.88
27 3.53 0.83 4.01 0.84 4.16 0.86 4.25 0.87 4.34 0.87 4.55 0.89 4.78 0.90
29 3.53 0.85 3.92 0.86 4.08 0.88 4.17 0.89 4.27 0.89 4.48 0.91 4.72 0.92
31 3.53 0.87 3.84 0.88 4.01 0.90 4.10 0.91 4.20 0.92 4.42 0.93 4.66 0.94
33 3.53 0.89 3.76 0.91 3.94 0.92 4.03 0.93 4.13 0.94 4.36 0.95 4.61 0.97
35 3.53 0.91 3.69 0.93 3.87 0.94 4.00 0.95 4.08 0.96 4.31 0.97 4.57 0.99
37 3.53 0.94 3.62 0.95 3.81 0.97 3.91 0.98 4.02 0.98 4.26 1.00 4.53 1.01
39 3.53 0.96 3.56 0.98 3.76 0.99 3.86 1.00 3.98 1.01 4.22 1.02 4.49 1.03
42 3.53 1.00 3.48 1.01 3.69 1.03 3.80 1.03 3.92 1.04 4.17 1.06 4.46 1.07
44 3.53 1.02 3.44 1.04 3.65 1.05 3.76 1.06 3.89 1.07 4.15 1.08 4.44 1.09
46 3.53 1.05 3.39 1.06 3.61 1.08 3.73 1.08 3.86 1.09 4.13 1.11 4.42 1.12
NOTE
 The performance table shows the average value of each conditions.
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU
 The total ability of connected a indoor unit is up to 6.0kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
