136
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, DB)
14 16 18 20 21 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2000 3500 5500 110%
-15 3.21 1.03 3.11 1.04 3.02 1.05 2.98 1.06 2.94 1.07 2.87 1.08 2.82 1.09
-10 3.84 1.08 3.73 1.10 3.64 1.11 3.60 1.12 3.55 1.12 3.48 1.13 3.42 1.14
-5 4.48 1.13 4.36 1.15 4.26 1.16 4.22 1.17 4.17 1.18 4.09 1.19 4.03 1.20
0 5.11 1.19 4.99 1.20 4.89 1.22 4.84 1.23 4.79 1.23 4.71 1.25 4.63 1.26
2 5.37 1.21 5.25 1.22 5.14 1.24 5.09 1.25 5.04 1.26 4.95 1.27 4.88 1.28
7 5.88 1.25 5.75 1.27 5.64 1.28 5.60 1.29 5.54 1.30 5.44 1.31 5.36 1.33
10 6.39 1.29 6.26 1.31 6.14 1.33 6.08 1.34 6.03 1.34 5.94 1.36 5.85 1.37
15 7.03 1.34 6.89 1.36 6.77 1.38 6.71 1.39 6.65 1.40 6.55 1.41 6.46 1.43
2500 2500 5000 100%
-15 3.21 1.02 3.11 1.03 3.02 1.05 2.98 1.05 2.94 1.06 2.87 1.07 2.82 1.08
-10 3.84 1.07 3.73 1.09 3.64 1.10 3.60 1.11 3.55 1.11 3.48 1.12 3.42 1.13
-5 4.48 1.12 4.36 1.14 4.26 1.16 4.22 1.16 4.17 1.17 4.09 1.18 4.03 1.19
0 5.11 1.18 4.99 1.19 4.89 1.21 4.84 1.22 4.79 1.22 4.71 1.24 4.63 1.25
2 5.37 1.20 5.25 1.21 5.14 1.23 5.09 1.24 5.04 1.25 4.95 1.26 4.88 1.27
7 5.88 1.24 5.75 1.26 5.64 1.27 5.60 1.28 5.54 1.29 5.44 1.30 5.36 1.32
10 6.39 1.28 6.26 1.30 6.14 1.32 6.08 1.32 6.03 1.33 5.94 1.35 5.85 1.36
15 7.03 1.33 6.89 1.35 6.77 1.37 6.71 1.38 6.65 1.39 6.55 1.40 6.46 1.41
2500 3500 6000 120%
-15 3.21 1.03 3.11 1.04 3.02 1.05 2.98 1.06 2.94 1.07 2.87 1.08 2.82 1.09
-10 3.84 1.08 3.73 1.10 3.64 1.11 3.60 1.12 3.55 1.12 3.48 1.13 3.42 1.14
-5 4.48 1.13 4.36 1.15 4.26 1.16 4.22 1.17 4.17 1.18 4.09 1.19 4.03 1.20
0 5.11 1.19 4.99 1.20 4.89 1.22 4.84 1.23 4.79 1.23 4.71 1.25 4.63 1.26
2 5.37 1.21 5.25 1.22 5.14 1.24 5.09 1.25 5.04 1.26 4.95 1.27 4.88 1.28
7 5.88 1.25 5.75 1.27 5.64 1.28 5.60 1.29 5.54 1.30 5.44 1.31 5.36 1.33
10 6.39 1.29 6.26 1.31 6.14 1.33 6.08 1.34 6.03 1.34 5.94 1.36 5.85 1.37
15 7.03 1.34 6.89 1.36 6.77 1.38
6.71 1.39 6.65 1.40 6.55 1.41 6.46 1.43
3500 3500 7000 140%
-15 3.21 1.03 3.11 1.05 3.02 1.06 2.98 1.07 2.94 1.07 2.87 1.08 2.82 1.09
-10 3.84 1.09 3.73 1.10 3.64 1.12 3.60 1.12 3.55 1.13 3.48 1.14 3.42 1.15
-5 4.48 1.14 4.36 1.16 4.26 1.17 4.22 1.18 4.17 1.19 4.09 1.20 4.03 1.21
0 5.11 1.19 4.99 1.21 4.89 1.23 4.84 1.24 4.79 1.24 4.71 1.26 4.63 1.27
2 5.37 1.22 5.25 1.23 5.14 1.25 5.09 1.26 5.04 1.27 4.95 1.28 4.88 1.29
7 5.88 1.26 5.75 1.28 5.64 1.29 5.60 1.30 5.54 1.31 5.44 1.32 5.36 1.34
10 6.39 1.30 6.26 1.32 6.14 1.34 6.08 1.35 6.03 1.35 5.94 1.37 5.85 1.38
15 7.03 1.35 6.89 1.37 6.77 1.39 6.71 1.40 6.65 1.41 6.55 1.42 6.46 1.44
NOTE
 The performance table shows the average value of each conditions.
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU
 The total ability of connected a indoor unit is up to 7.0kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
