Samsung AR07TXEAAWKNEU - Page 14

14
2. Specification
Type FREE JOINT MULTI FREE JOINT MULTI FREE JOINT MULTI
Model Name AJ068TXJ3KG/EU AJ080TXJ4KG/EU AJ100TXJ5KG/EU
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection Flare connection
Φ, mm
x EA
6.35 x 3 6.35 x 4 6.35 x 5
Φ, inch
x EA
1/4 x 3 1/4 x 4 1/4 x 5
Gas Pipe
Type Flare connection Flare connection Flare connection
Φ, mm
x EA
9.52 + 12.70 x 2 9.52 x 2 + 12.70 x 2 9.52 x 2 + 12.70 x 3
Φ, inch
x EA
3/8 + 1/2 x 2 3/8 x 2 + 1/2 x 2 3/8 x 2 + 1/2 x 3
Heat insulation Both Liquid & Gas pipes Both Liquid & Gas pipes Both Liquid & Gas pipes
Installation
Limitation
Length
Total Piping Length m 50 70 75
Max. Length (OD~ID) m 25 25 25
Height
Max. Height (OD~ID) m 15 15 15
Max. Height (ID~ID) m 7. 5 7.5 7. 5
Wiring
Connections
Communication
Min.
mm
2
0.75 0.75 0.75
Remark - F1, F2 F1, F2 F1, F2
Refrigerant
Type - R32 R32 R32
Factory Charging
kg 2.00 2.00 2.70
tCO
2
e 1.35 1.35 1.82
Sound
Sound Pressure
Cooling
dB(A)
48 48 54
Heating 50 50 56
Sound Power dBA 64 64 70
External
Dimension
Net Weight kg 5 7. 5 57. 5 76.5
Shipping Weight kg 61.5 61.5 82.0
Net Dimensions (WxHxD) mm 880 x 798 x 310 880 x 798 x 310 940 x 998 x 330
Shipping Dimensions (WxHxD) mm 1,023 x 896 x 413 1,023 x 896 x 413 995 x 1,096 x 426
Operating
Temp. Range
Cooling ℃ -10.0 ~ 46.0 -10.0 ~ 46.0 -10.0 ~ 46.0
Heating ℃ -15.0 ~ 24.0 -15.0 ~ 24.0 -15.0 ~ 24.0
NOTE
 
 1 )* Capacities are based on (Equivalent refrigerant piping : 5m, Level differences : 0m)
- Cooling : Indoor temperature : 27°C DB, 19°C WB / Outdoor temperature : 35°C DB, 24°C WB
- Heating : Indoor temperature : 20°C DB, 15°C WB / Outdoor temperature : 7°C DB, 6°C WB
 2)* Select wire size based on the value of MCA
 3)* Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level
- Reference acoustic pressure 0 dB = 20uPa
 4)* Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
- Reference power : 1pW
- Measured according to ISO 3741
 
2. Specification
