12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, WB)
14 16 18 19 20 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 3500 8500 163%
10 5.85 0.88 6.08 0.90 6.31 0.91 6.43 0.92 6.55 0.93 6.79 0.95 7.03 0.97
12 5.75 0.90 5.98 0.92 6.21 0.94 6.33 0.95 6.45 0.96 6.69 0.98 6.93 0.99
14 5.64 0.92 5.87 0.94 6.11 0.96 6.23 0.97 6.35 0.98 6.59 1.00 6.83 1.02
16 5.54 0.95 5.77 0.97 6.01 0.99 6.13 1.00 6.25 1.01 6.49 1.03 6.73 1.04
18 5.44 0.97 5.67 0.99 5.91 1.01 6.03 1.02 6.15 1.03 6.39 1.05 6.63 1.07
20 5.34 1.00 5.57 1.02 5.81 1.04 5.93 1.05 6.05 1.06 6.29 1.08 6.54 1.10
21 5.29 1.01 5.52 1.03 5.76 1.05 5.88 1.06 6.00 1.07 6.24 1.09 6.49 1.11
23 5.19 1.04 5.42 1.06 5.66 1.08 5.78 1.09 5.90 1.10 6.14 1.12 6.39 1.14
25 5.09 1.06 5.32 1.08 5.56 1.10 5.68 1.11 5.80 1.12 6.04 1.14 6.29 1.16
27 4.99 1.09 5.23 1.11 5.46 1.13 5.58 1.14 5.70 1.15 5.95 1.17 6.19 1.19
29 4.89 1.12 5.13 1.14 5.36 1.16 5.48 1.17 5.60 1.18 5.85 1.20 6.10 1.22
31 4.79 1.15 5.03 1.17 5.27 1.19 5.39 1.20 5.51 1.21 5.75 1.23 6.00 1.25
33 4.69 1.17 4.93 1.19 5.17 1.21 5.29 1.22 5.41 1.23 5.65 1.25 5.90 1.27
35 4.60 1.20 4.83 1.22 5.07 1.24 5.20 1.25 5.31 1.26 5.56 1.28 5.81 1.30
37 4.50 1.23 4.73 1.25 4.97 1.27 5.09 1.28 5.22 1.29 5.46 1.31 5.71 1.33
39 4.40 1.26 4.64 1.28 4.88 1.30 5.00 1.31 5.12 1.32 5.36 1.34 5.61 1.36
42 4.25 1.31 4.49 1.33 4.73 1.35 4.85 1.36 4.97 1.37 5.22 1.39 5.47 1.41
44 4.16 1.34 4.39 1.36 4.63 1.38 4.76 1.39 4.88 1.40 5.13 1.42 5.38 1.44
46 4.06 1.37 4.30 1.39 4.54 1.41 4.66 1.42 4.78 1.43 5.03 1.45 5.28 1.47
NOTE
 Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
 Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU
 Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
 The total ability of connected a indoor unit is up to 7.5kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
