150
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, DB)
14 16 18 20 21 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 2500 7500 144%
-15 3.61 1.11 3.49 1.13 3.39 1.14 3.35 1.15 3.31 1.16 3.23 1.17 3.17 1.18
-10 4.32 1.17 4.20 1.19 4.09 1.20 4.04 1.21 4.00 1.22 3.92 1.23 3.85 1.24
-5 5.03 1.23 4.91 1.25 4.79 1.26 4.74 1.27 4.69 1.28 4.61 1.29 4.53 1.30
0 5.75 1.29 5.62 1.31 5.50 1.32 5.44 1.33 5.39 1.34 5.30 1.35 5.21 1.36
2 6.04 1.31 5.90 1.33 5.78 1.35 5.72 1.35 5.67 1.36 5.57 1.38 5.49 1.39
7 6.61 1.35 6.47 1.37 6.34 1.39 6.30 1.40 6.23 1.41 6.12 1.43 6.03 1.44
10 7.19 1.40 7.04 1.42 6.91 1.44 6.84 1.45 6.79 1.46 6.68 1.47 6.58 1.49
15 7.91 1.46 7.75 1.48 7. 6 1 1.50 7.55 1.51 7.49 1.52 7.37 1.53 7.27 1.55
2500 2500 3500 8500 163%
-15 3.61 1.05 3.49 1.06 3.39 1.08 3.35 1.09 3.31 1.09 3.23 1.10 3.17 1.11
-10 4.32 1.10 4.20 1.12 4.09 1.14 4.04 1.14 4.00 1.15 3.92 1.16 3.85 1.17
-5 5.03 1.16 4.91 1.18 4.79 1.19 4.74 1.20 4.69 1.21 4.61 1.22 4.53 1.23
0 5.75 1.21 5.62 1.23 5.50 1.25 5.44 1.25 5.39 1.26 5.30 1.28 5.21 1.29
2 6.04 1.23 5.90 1.25 5.78 1.27 5.72 1.28 5.67 1.28 5.57 1.30 5.49 1.31
7 6.61 1.28 6.47 1.30 6.34 1.31 6.30 1.32 6.23 1.33 6.12 1.34 6.03 1.36
10 7.19 1.32 7.04 1.34 6.91 1.36 6.84 1.37 6.79 1.37 6.68 1.39 6.58 1.40
15 7.91 1.37 7.75 1.39 7. 6 1 1.41 7.55 1.42 7. 49 1.43 7.37 1.45 7.27 1.46
NOTE
 Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
 Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU
 Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
 The total ability of connected a indoor unit is up to 7.5kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
