2. Specification
2-2. Indoor units
AR4500
Type AR4500 AR4500
Model Name AR18TXHZAWKNEU AR24TXHZAWKNEU
Power Supply
Ø, #, V,
Hz
1,2,220-240,50 1,2,220-240,50
Mode - HP HP
Performance
Capacity
Cooling
kW 5 6.5
Btu/h 17,100 22,200
Heating
kW 6 7.4
Btu/h 20,500 25,300
Power
Power Input
Cooling W 40 50
Heating W 40 50
Current Input
Cooling A 0.4 0.5
Heating A 0.4 0.5
Heat
Exchanger
Type - Fin & Tube Fin & Tube
Material
Fin - Al Al
Tube - Cu Cu
Fin Treatment - Green Hydrophile Green Hydrophile
Fan
Type - Cross Flow Cross Flow
Quantity EA 1 1
Air Flow Rate
Cooling (T/H/M/L)
m³/min 15.3 / 14.8 / 13.7 / 12.7 16.4 / 15.3 / 14.2 / 13.1
l/s 256 / 247 / 229 / 211 274 / 255 / 237 / 218
Heating (T/H/M/L)
m³/min 15.5 / 15.0 / 13.9 / 12.8 17.1 / 16.0 / 14.9 / 13.8
l/s 258 / 249 / 231 / 213 286 / 267 / 248 / 229
Fan Motor
Type - BLDC BLDC
Output W x n 27 x 1 27 x 1
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
12.7 (1/2) 15.88 (5/8)
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes
Drain Pipe Φ,
mm 16.3, 550 16.3, 550
Wiring
connections
Communication
Min.
mm
2
0.75 0.75
Remark - F1, F2 F1, F2
Refrigerant
Type - R32 R32
Electronic Expansion Valve - EEV NOT INCLUDED EEV NOT INCLUDED
