171
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, DB)
14 16 18 20 21 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 3500 8500 125%
-15 4.58 1.52 4.44 1.54 4.31 1.56 4.25 1.57 4.20 1.58 4.10 1.59 4.02 1.61
-10 5.49 1.60 5.33 1.62 5.20 1.64 5.14 1.65 5.08 1.66 4.97 1.68 4.89 1.69
-5 6.39 1.68 6.23 1.70 6.09 1.72 6.02 1.73 5.96 1.74 5.85 1.76 5.75 1.78
0 7.30 1.76 7.13 1.78 6.98 1.80 6.91 1.82 6.84 1.83 6.72 1.85 6.62 1.86
2 7.67 1.79 7.49 1.81 7.34 1.84 7.27 1.85 7.20 1.86 7.0 7 1.88 6.97 1.90
7 8.40 1.85 8.22 1.88 8.05 1.90 8.00 1.91 7.91 1.92 7.78 1.94 7.66 1.96
10 9.12 1.91 8.94 1.94 8.77 1.96 8.69 1.98 8.62 1.99 8.48 2.01 8.36 2.03
15 10.04 1.99 9.84 2.02 9.67 2.04 9.58 2.06 9.51 2.07 9.36 2.09 9.23 2.11
2500 2500 5000 10000 147%
-15 4.58 1.55 4.44 1.57 4.31 1.59 4.25 1.60 4.20 1.61 4.10 1.63 4.02 1.64
-10 5.49 1.63 5.33 1.66 5.20 1.68 5.14 1.69 5.08 1.70 4.97 1.71 4.89 1.73
-5 6.39 1.71 6.23 1.74 6.09 1.76 6.02 1.77 5.96 1.78 5.85 1.80 5.75 1.81
0 7.30 1.79 7.13 1.82 6.98 1.84 6.91 1.85 6.84 1.86 6.72 1.88 6.62 1.90
2 7.67 1.82 7. 49 1.85 7.34 1.88 7.27 1.89 7.20 1.90 7.07 1.92 6.97 1.94
7 8.40 1.89 8.22 1.92 8.05 1.94 8.00 1.95 7.91 1.96 7.78 1.99 7.66 2.00
10 9.12 1.95 8.94 1.98 8.77 2.01 8.69 2.02 8.62 2.03 8.48 2.05 8.36 2.07
15 10.04 2.03 9.84 2.06 9.67 2.09 9.58 2.10 9.51 2.11 9.36 2.14 9.23 2.16
2500 3500 3500 9500 140%
-15 4.58 1.53 4.44 1.56 4.31 1.58 4.25 1.59 4.20 1.60 4.10 1.61 4.02 1.62
-10 5.49 1.61 5.33 1.64 5.20 1.66 5.14 1.67 5.08 1.68 4.97 1.70 4.89 1.71
-5 6.39 1.69 6.23 1.72 6.09 1.74 6.02 1.75 5.96 1.76 5.85 1.78 5.75 1.80
0 7.30 1.77 7.13 1.80 6.98 1.82 6.91 1.83 6.84 1.85 6.72 1.86 6.62 1.88
2 7.67 1.80 7.49 1.83 7.34 1.86 7.27 1.87 7.20 1.88 7.07 1.90 6.97 1.92
7 8.40 1.87 8.22 1.90 8.05 1.92 8.00 1.93 7.91 1.94 7.78 1.96 7.66 1.98
10 9.12 1.93 8.94 1.96 8.77 1.99 8.69 2.00 8.62 2.01 8.48 2.03 8.36 2.05
15 10.04 2.01 9.84
2.04 9.67 2.07 9.58 2.08 9.51 2.09 9.36 2.11 9.23 2.13
2500 3500 5000 11000 162%
-15 4.58 1.57 4.44 1.60 4.31 1.62 4.25 1.63 4.20 1.64 4.10 1.65 4.02 1.67
-10 5.49 1.66 5.33 1.68 5.20 1.70 5.14 1.71 5.08 1.72 4.97 1.74 4.89 1.75
-5 6.39 1.74 6.23 1.76 6.09 1.79 6.02 1.80 5.96 1.81 5.85 1.83 5.75 1.84
0 7.30 1.82 7.13 1.85 6.98 1.87 6.91 1.88 6.84 1.89 6.72 1.91 6.62 1.93
2 7.67 1.85 7. 49 1.88 7.34 1.90 7.27 1.92 7.20 1.93 7.07 1.95 6.97 1.96
7 8.40 1.92 8.22 1.94 8.05 1.97 8.00 1.98 7.91 1.99 7.78 2.02 7.66 2.03
10 9.12 1.98 8.94 2.01 8.77 2.04 8.69 2.05 8.62 2.06 8.48 2.08 8.36 2.10
15 10.04 2.06 9.84 2.09 9.67 2.12 9.58 2.13 9.51 2.14 9.36 2.17 9.23 2.19
3500 3500 3500 10500 154%
-15 4.58 1.52 4.44 1.54 4.31 1.56 4.25 1.57 4.20 1.58 4.10 1.59 4.02 1.61
-10 5.49 1.60 5.33 1.62 5.20 1.64 5.14 1.65 5.08 1.66 4.97 1.68 4.89 1.69
-5 6.39 1.68 6.23 1.70 6.09 1.72 6.02 1.73 5.96 1.74 5.85 1.76 5.75 1.78
0 7.30 1.76 7.13 1.78 6.98 1.80 6.91 1.82 6.84 1.83 6.72 1.85 6.62 1.86
2 7.67 1.79 7.49 1.81 7.34 1.84 7.27 1.85 7.20 1.86 7.0 7 1.88 6.97 1.90
7 8.40 1.85 8.22 1.88 8.05 1.90 8.00 1.91 7.91 1.92 7.78 1.94 7.66 1.96
10 9.12 1.91 8.94 1.94 8.77 1.96 8.69 1.98 8.62 1.99 8.48 2.01 8.36 2.03
15 10.04 1.99 9.84 2.02 9.67 2.04 9.58 2.06 9.51 2.07 9.36 2.09 9.23 2.11
NOTE
Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU
Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
The total ability of connected a indoor unit is up to 7.5kW
It is impossible to connect the indoor unit for one room only.
This data is reference data for temperature capacity trend.
