2. Specification
2-2. Indoor units
AR9500
Type AR9500 AR9500
Model Name AR18TXFCAWKNEU AR24TXFCAWKNEU
Power Supply
Ø, #, V,
Hz
1,2,220-240,50 1,2,220-240,50
Mode - HP HP
Performance
Capacity
Cooling
kW
5 6.5
Btu/h 17,100 22,200
Heating
kW
6 7.4
Btu/h 20,500 25,300
Power
Power Input
Cooling W
40 50
Heating W 40 50
Current Input
Cooling A
0.4 0.5
Heating A 0.4 0.5
Heat
Exchanger
Type - Fin & Tube Fin & Tube
Material
Fin - Al Al
Tube - Cu Cu
Fin Treatment - Green Hydrophile Green Hydrophile
Fan
Type - Cross Flow Cross Flow
Quantity EA 1 1
Air Flow Rate
Cooling (T/H/M/L)
m³/min
15.3 / 14.3 / 13.3 / 12.2 16.4 / 15.3 / 14.3 / 12.7
l/s 256 / 238 / 221 / 204 274 / 256 / 238 / 211
Heating (T/H/M/L)
m³/min
15.5 / 14.5 / 13.4 / 12.4 17.1 / 16.0 / 15.0 / 13.3
l/s 258 / 241 / 223 / 206 286 / 267 / 249 / 222
Fan Motor
Type - BLDC BLDC
Output W x n 27 x 1 27 x 1
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
12.7 (1/2) 15.88 (5/8)
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes
Drain Pipe Φ,
mm 16.3, 550 16.3, 550
Wiring
connections
Communication
Min.
mm
2
0.75 0.75
Remark - F1, F2 F1, F2
Refrigerant
Type - R32 R32
Electronic Expansion Valve - EEV NOT INCLUDED EEV NOT INCLUDED
Sound
Sound Pressure Level H / Silent dB(A)
41 / 28 45 / 29
Sound Power Level dB(A) 58 62
