2. Specification
2-2. Indoor units
AR9500
Type AR9500 AR9500 AR9500
Model Name AR07TXEAAWKNEU AR09TXEAAWKNEU AR12TXEAAWKNEU
Power Supply
Ø, #, V,
Hz
1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode - HP HP HP
Performance
Capacity
Cooling
kW
2.0 2.5 3.5
Btu/h 6,800 8,500 11,900
Heating
kW
2.2 3.2 4.0
Btu/h 7,500 10,900 13,600
Power
Power Input
Cooling W
40 40 40
Heating W 40 40 40
Current Input
Cooling A
0.4 0.4 0.4
Heating A 0.4 0.4 0.4
Heat
Exchanger
Type -
Fin & Tube Fin & Tube Fin & Tube
Material
Fin -
Al Al Al
Tube - Cu Cu Cu
Fin Treatment - Green Hydrophile Green Hydrophile Green Hydrophile
Fan
Type -
Cross Flow Cross Flow Cross Flow
Quantity EA 1 1 1
Air Flow Rate
Cooling (T/H/M/L)
m³/min
9.2 / 8.6 / 8.6 / 7.1 9.5 / 9.0 / 8.5 / 7.4 10.5 / 10.0 / 9.0 / 7.9
l/s 153 / 144 / 143 / 118 158 / 150 / 142 / 123 175 / 167 / 150 / 132
Heating (T/H/M/L)
m³/min
10.7 / 10.1 / 10.0 / 9.0 11.1 / 10.5 / 10.0 / 9.0 12.1 / 11.6 / 10.5 / 9.5
l/s 178 / 168 / 166 / 150 185 / 175 / 167 / 150 202 / 193 / 175 / 158
Fan Motor
Type -
BLDC BLDC BLDC
Output W x n 27 x 1 27 x 1 27 x 1
Piping
Connections
Liquid Pipe
Type
Flare connection Flare connection Flare connection
Φ, mm
(inch)
6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type
Flare connection Flare connection Flare connection
Φ, mm
(inch)
9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
Heat Insulation -
Both liquid and gas
pipes
Both liquid and gas
pipes
Both liquid and gas
pipes
Drain Pipe Φ, mm 16.3, 550 16.3, 550 16.3, 550
Wiring
connections
Communication
Min.
mm
2
0.75 0.75 0.75
Remark - F1, F2 F1, F2 F1, F2
Refrigerant
Type -
R32 R32 R32
Electronic Expansion Valve - EEV NOT INCLUDED EEV NOT INCLUDED EEV NOT INCLUDED
Sound
Sound Pressure Level H / Silent dB(A)
37 / 19 38 / 19 40 / 19
Sound Power Level dB(A) 54 54 57
