29
2. Specification
2-2. Indoor units
AR9500
Type AR9500 AR9500
Model Name AR18TXEAAWKNEU AR24TXEAAWKNEU
Power Supply
Ø, #, V,
Hz
1,2,220-240,50 1,2,220-240,50
Mode - HP HP
Performance
Capacity
Cooling
kW
5 6.5
Btu/h 17100 22,200
Heating
kW
6 7.4
Btu/h 20500 25,300
Power
Power Input
Cooling W
40 50
Heating W 40 50
Current Input
Cooling A
0.4 0.5
Heating A 0.4 0.5
Heat
Exchanger
Type - Fin & Tube Fin & Tube
Material
Fin - Al Al
Tube - Cu Cu
Fin Treatment - Green Hydrophile Green Hydrophile
Fan
Type - Cross Flow Cross Flow
Quantity EA 1 1
Air Flow Rate
Cooling (T/H/M/L)
m³/min
15.3 / 14.3 / 13.3 / 11.8 16.4 / 14.9 / 13.5 / 11.5
l/s 256 / 239 / 222 / 197 274 / 249 / 225 / 192
Heating (T/H/M/L)
m³/min
15.0 / 14.0 / 13.0 / 11.6 17.1 / 15.6 / 14.2 / 12.2
l/s 250 / 234 / 217 / 193 286 / 261 / 236 / 203
Fan Motor
Type - BLDC BLDC
Output W x n 27 x 1 27 x 1
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type Flare connection Flare connection
Φ,
mm
(inch)
12.7 (1/2) 15.88 (5/8)
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes
Drain Pipe Φ,
mm 16.3, 550 16.3, 550
Wiring
connections
Communication
Min.
mm
2
0.75 0.75
Remark - F1, F2 F1, F2
Refrigerant
Type - R32 R32
Electronic Expansion Valve - EEV NOT INCLUDED EEV NOT INCLUDED
Sound
Sound Pressure Level H / Silent dB(A)
41 / 28 45 / 29
Sound Power Level dB(A) 58 62
