13. Installation
13. Installation
Choosing the installation location
Installation location requirements
The outdoor unit shall be installed in an open space
that is always ventilated.
The local gas regulations shall be observed.
For installation inside a building (this applies
either to indoor or outdoor units installed inside) a
the reference table into either the indoor or outdoor
unit installation manual).
To handle, purge, and dispose the refrigerant, or
break into the refrigerant circuit, the worker should
authority.
Do not install the indoor unit in the following areas:
-
It will deteriorate plastic parts, causing failure or
leakage.
- Area that is close to heat sources.
- Area that produces substances such as sulfuric
gas, chlorine gas, acid, and alkali. It may cause
- Area that can cause leakage of combustible gas
- Area where refrigerant leaks and settles.
- Area where animals may urinate on the product.
Ammonia may be generated.
Do not use the indoor unit for preservation of food
items, plants, equipment, and art works. This may
cause deterioration of their quality.
Do not install the indoor unit if it has any drainage
problem.
Do not place the outdoor unit on its side or upside
down. Failing to do so may cause the compressor
lubrication oil to run into the cooling circuit and lead
to a serious damage to the unit.
Install the unit in a well-ventilated location away
from direct sunlight or strong winds.
Install the unit in a location that would not obstruct
any passageways or thoroughfares.
Install the unit in a location that would not inconvenience
or disturb your neighbors, as they could be affected by the
Install the unit in a location where the pipes and the cables
can be easily connected to the indoor unit.
the weight of the unit. Otherwise, the unit can generate
noise and vibration during operation.
open area.
unit, especially from a radio, computer, stereo
system, etc.
Fuse
Fuse
Control
1.5 m or more
1 m or more
1 m or more
1.5 m or more
1.5 m or more
300 mm
Stereo
Computer
etc
Outdoor Unit
200 mm
Air Guide Duct (This product is not provided by Samsung)
Indoor Unit
Install the unit at a height where its base can be
Make sure that the water dripping from the drain
hose runs away correctly and safely.
