※ In case you want more information about the controllers and accessories, please refer to the Controller and Accessory TDB
on pvi.Samsung.com site or Global Partner Portal site.
13. Installation
Because your air conditioner contains R-32
refrigerant, make sure that it is installed, operated,
the following table:
Minimum required room area (A,m²)
m (kg)
Ceiling-
mounted
Wall-mounted Floor-standing
No requirement
1.843 3.64 4.45 28.9
1.9 3.75 4.58 30.7
2.0 3.95 4.83 34.0
2.2 4.34 5.31 41.2
2.4 4.74 5.79 49.0
2.6 5.13 6.39 5 7. 5
2.8 5.53 7.41 66.7
3.0 5.92 8.51 76.6
3.2 6.48 9.68 87.2
3.4 7.32 10.9 98.4
3.6 8.20 12.3 110
3.8 9.14 13.7 123
4.0 10.1 15.1 136
4.2 11.2 16.7 150
4.4 12.3 18.3 165
4.6 13.4 20.0 180
4.8 14.6 21.8 196
5.0 15.8 23.6 213
- m : Total refrigerant charge in the system
-
IMPORTANT: it’s mandatory to consider either the
table above or taking into consideration the local law
regarding the minimum living space of the premises.
Minimum installation height of indoor unit is 0.6 m
CAUTION
3 m as minimum pipe length: It will reduce noise and
vibration.
the nuts could be broken so refrigerant may leak.
Protect or enclose refrigerant tubing to avoid
mechanical damage.
NOTE
The appearance of the unit may be different from the
diagram depending on the model.
You can use the Cool and Heat modes in the
following conditions :
Model Cool Heat
Outdoor
temperature
-10 °C to 46 °C -15 °C to 24 °C
- It could take maximum 60 minutes to operate for
the protection of the compressor,if the outdoor
temperature is below -5°C.
Connecting up and removing air in the circuit
WARNING
When installing, make sure there is no leakage. When
recovering the refrigerant, ground the compressor
refrigerant pipe is not properly connected and the
compressor works with the service valve open, the
pipe inhales the air and it makes the pressure inside
of the refrigerant cycle abnormally high. It may cause
refrigerant.Do not vent R-32 into atmosphere: it is a
with a Global Warming Potential (GWP) = 675.
You should purge the air in the indoor unit and in the
pipe. If air remains in the refrigerant pipes, it affects the
compressor. It may cause reduction of cooling capacity
and malfunction. Refrigerant for air purging is not
charged in the outdoor unit. Use Vacuum Pump as seen
in the picture.
