39
2. Specification
2-2. Indoor units
Duct
Type Home Duct Home Duct Home Duct
Model AJ026TNLDEG/EU AJ035TNLDEG/EU AJ026TNLPEG/EU
Power Supply Φ, #, V, Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode - HP HP HP
Performance
Capacity
(Nominal)
Cooling 2)
kW 2.6 3.5 2.6
Btu/h 8,900 11,900 8,900
Heating 2)
kW 2.9 3.8 2.9
Btu/h 9,900 13,000 9,900
Power
Power Input
(Nominal)
Cooling 1) W 80 80 80
Heating 2) 80 80 80
Current Input
(Nominal)
Cooling 1) A 0.4 0.4 0.4
Heating 2) 0.4 0.4 0.4
Fan
Motor
Type - Sirroco Fan / BLDC Sirroco Fan / BLDC Sirroco Fan / BLDC
Output x n W 69 x 1 69 x 1 69 x 1
Air Flow Rate H/M/L (UL)
CMM 9.1 / 7.7 / 5.7 9.5 / 7.9 / 6.2 9.1 / 7.7 / 5.7
l/s 152 / 128 / 95 158 / 131 / 103 152 / 128 / 95
External
Pressure
Min / Std / Max
mmAq 0 / 1 / 3 0 / 1 / 3 0 / 1 / 3
Pa 0 / 9.8 / 29.4 0 / 9.8 / 29.4 0 / 9.8 / 29.4
Piping
Connections
Liquid Pipe
Φ,mm 6.35 6.35 6.35
Φ, inch 1/4 1/4 1/4
Gas Pipe
Φ,mm 9.52 9.52 9.52
Φ, inch 3/8 3/8 3/8
Drain Pipe Φ,mm VP25 (OD 32, ID 25) VP25 (OD 32, ID 25) VP25 (OD 32, ID 25)
Field
Wiring
Power Source Wire mm2 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Transmission Cable mm2 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Refrigerant
Type - R32 R32 R32
Control Method - EEV NOT INCLUDED EEV NOT INCLUDED EEV NOT INCLUDED
Sound
Sound Pressure H/M/L dB(A) 33 / 29 / 23 34 / 30 / 25 33 / 29 / 23
Sound Power Cooling 50 50 50
Dimensions
Net Weight kg 14.8 14.8 15.0
Shipping Weight kg 1 7.7 17.7 18.0
Net Dimensions (W×H×D) mm 700 x 199 x 440 700 x 199 x 440 700 x 199 x 440
Shipping Dimensions (W×H×D) mm 949 x 280 x 544 949 x 280 x 544 949 x 280 x 544
Casing Material - HIPS HIPS HIPS
Drain pump
Drain pump - NOT INCLUDED NOT INCLUDED INCLUDED
Max. lifting Height / Displacement
mm / Liter/
h
- - 1200/24
