4. Combination Table4. Combination Table
HEATING
Outdoor unit A B C D
Heating
Capacity
Capacity
Power
Consumption
Current
Efc.
NOM.
Heating.
At
7℃/20℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SCOP
P
design
Qhe
W W W A
A B C D MIN STD MAX MIN STD MAX MIN STD MAX COP Class kW kWh
AJ080TXJ4KG
2 Unit
7 7 2200 2200 1980 4400 5060 600 1150 1530 2.7 4.9 7. 0 3.83 A+ 4.25 3.05 1006
7 9 2040 3060 2040 5100 5870 610 1290 1700 2.8 5.5 7.8 3.95 A+ 4.20 4.21 1401
7 12 2130 3870 2110 6000 6900 610 1530 2110 2.8 6.5 9.7 3.92 A+ 4.11 4.91 1669
7 18 2090 5710 2200 7800 9130 620 1920 2580 2.8 8.2 11.8 4.06 A+ 4.18 5.09 1705
7 24 1790 6330 2200 8120 9300 620 2000 2600 2.8 8.5 11.9 4.06 A+ 4.18 5.2 1742
9 9 2900 2900 2100 5800 6670 610 1470 1930 2.8 6.3 8.8 3.94 A+ 4.11 4.91 1669
9 12 3030 3670 2170 6700 7710 610 1730 2330 2.8 7.4 10.7 3.87 A+ 4.11 4.91 1669
9 18 2770 5030 2200 7800 9360 620 1920 2600 2.8 8.2 11.9 4.06 A+ 4.18 5.09 1705
9 24 2480 5870 2200 8350 9600 620 2220 2700 2.8 9.5 12.4 3.94 A+ 4.18 5.2 1742
12 12 3800 3800 2200 7600 8740 620 1890 2510 2.8 8.1 11.5 4.02 A+ 4.18 5.09 1705
12 18 3250 4870 2200 8120 9500 620 2000 2650 2.8 8.5 12.1 4.06 A+ 4.18 5.09 1705
12 24 2860 5590 2200 8450 9700 620 2100 2700 2.8 8.9 12.4 4.02 A+ 4.18 5.09 1705
18 18 4250 4250 2200 8500 9950 620 2080 2750 2.8 8.9 12.6 4.09 A+ 4.10 5.88 2010
18 24 3760 4890 2200 8650 9900 620 2110 2800 2.8 9.0 12.8 4.10 A+ 4.10 5.88 2010
3 Unit
7 7 7 2200 2200 2200 2170 6600 7590 610 1540 2220 2.8 6.6 10.2 4.28 A+ 4.14 5.65 1912
7 7 9 2090 2090 3120 2200 7300 8400 620 1670 2340 2.8 7.1 10.7 4.37 A+ 4.10 5.88 2010
7 7 12 2150 2150 3900 2200 8200 9590 620 1950 2570 2.8 8.3 11.8 4.21 A+ 4.10 5.88 2010
7 7 18 1820 1820 4980 2200 8620 10090 620 2040 2610 2.8 8.7 11.9 4.23 A+ 4.10 5.88 2009
7 7 24 1580 1580 5590 2200 8750 10500 620 2080 2750 2.8 8.9 12.6 4.21
A+ 4.11 5.88 2003
7 9 9 2000 3000 3000 2200 8000 9360 620 1930 2500 2.8 8.2 11.4 4.14 A+ 4.10 5.88 2010
7 9 12 1980 2960 3590 2200 8530 9980 620 2000 2690 2.8 8.5 12.3 4.27 A+ 4.10 5.88 2009
7 9 18 1660 2490 4530 2200 8680 10150 620 2030 2740 2.8 8.6 12.5 4.28 A+ 4.10 5.88 2009
7 9 24 1540 2310 5450 2200 9300 10900 620 2150 2820 2.8 9.2 12.9 4.33 A+ 4.11 5.88 2003
7 12 12 1860 3370 3370 2200 8600 10070 620 2030 2740 2.8 8.6 12.5 4.24 A+ 4.10 5.88 2009
7 12 18 1580 2870 4300 2200 8750 10500 620 2080 2750 2.8 8.9 12.6 4.21 A+ 4.11 5.88 2003
7 18 18 1440 3930 3930 2200 9300 10900 620 2150 2820 2.8 9.2 12.9 4.33 A+ 4.11 5.88 2003
9 9 9 2840 2840 2840 2200 8520 9960 620 1990 2680 2.8 8.5 12.3 4.28 A+ 4.10 5.88 2009
9 9 12 2670 2670 3250 2200 8590 10050 620 2030 2690 2.8 8.6 12.3 4.23 A+ 4.10 5.88 2009
9 9 18 2290 2290 4170 2200 8750 10500 620 2080 2740 2.8 8.9 12.5 4.21 A+ 4.11 5.88 2003
9 9 24 2130 2130 5040 2200 9300 10900 620 2170 2820 2.8 9.2 12.9 4.29 A+ 4.11 5.88 2003
9 12 12 2520 3070 3070 2200 8660 10130 620 2040 2740 2.8 8.7 12.5 4.24 A+ 4.10 5.88 2009
9 12 18 2310 2800 4190 2200 9300 10500 620 2130 2750 2.8 9.1 12.6 4.37 A+ 4.11 5.88 2003
12 12 12 2910 2910 2910 2200 8730 10220 620 2070 2750 2.8 8.8 12.6 4.22 A+ 4.11 5.88 2003
12 12 18 2660 2660 3980 2200 9300 10900 620 2160 2790 2.8 9.2 12.8 4.31 A+ 4.11 5.88 2003
4 Unit
7 7 7 7 2130 2130 2130 2130 2200 8520 9970 620 1990 2690 2.8 8.9 12.3 4.28 A+ 4.11 5.88 2003
7 7 7 9 1910 1910 1910 2850 2200 8580 10040 620 2030 2690 2.8 9.0 12.3 4.23 A+ 4.11 5.88 2003
7 7 7 12 1800 1800 1800 3250 2200 8650 10120 620 2020 2740 2.8 9.0 12.5 4.28 A+ 4.11 5.88 2003
7 7 7 18 1620 1620 1620 4440 2200 9300 10900 620 2130 2820 2.8 9.5 12.9 4.37 A+ 4.11 5.88 2003
7 7 9 9 1730 1730 2590
2590 2200 8640 10100 620 2020 2740 2.8 9.0 12.5 4.28 A+ 4.11 5.88 2003
7 7 9 12 1640 1640 2460 2970 2200 8710 10190 620 2040 2740 2.8 9.1 12.5 4.27 A+ 4.11 5.88 2003
7 7 9 18 1490 1490 2240 4080 2200 9300 10900 620 2130 2820 2.8 9.5 12.9 4.37 A+ 4.11 5.88 2003
7 7 12 12 1560 1560 2830 2830 2200 8780 10270 620 2070 2790 2.8 9.2 12.8 4.24 A+ 4.11 5.88 2003
7 9 9 9 1580 2370 2370 2370 2200 8690 10170 620 2030 2740 2.8 9.0 12.5 4.28 A+ 4.11 5.88 2003
7 9 9 12 1510 2260 2260 2730 2200 8760 10250 620 2060 2790 2.8 9.2 12.8 4.25 A+ 4.11 5.88 2003
7 9 9 18 1390 2070 2070 3770 2200 9300 10900 620 2130 2820 2.8 9.5 12.9 4.37 A+ 4.11 5.88 2003
7 9 12 12 1520 2260 2760 2760 2200 9300 10900 620 2130 2820 2.8 9.5 12.9 4.37 A+ 4.11 5.88 2003
9 9 9 9 2190 2190 2190 2190 2200 8760 10240 620 2060 2740 2.8 9.2 12.5 4.25 A+ 4.11 5.88 2003
9 9 9 12 2210 2210 2210 2670 2200 9300 10900 620 2130 2790 2.8 9.5 12.8 4.37 A+ 4.11 5.88 2003
9 9 12 12 2100 2100 2550 2550 2200 9300 10900 620 2130 2820 2.8 9.5 12.9 4.37 A+ 4.11 5.88 2003
NOTE
1
EER and COP declared only for the purpose of tax deductions in force at the time of the creation of this catalog.
2
The above is the value for connecting with the following indoor units.
- Wind Free(PRM) : AR07TXCAAWK, AR09TXCAAWK, AR12TXCAAWK
3
You can not connect a single unit.
4
Power consumption include indoor unit power.
