77
6. Center of Gravity
6-2. Indoor unit
6
Home duct : AJ026TNLDEG/EU, AJ035TNLDEG/EU, AJ052TNMDEG/EU, AJ026TNLPEG/EU, AJ035TNLPEG/EU
Unit : mm
Model A B C
AJ026TNLDEG/EU, AJ035TNLDEG/EU,
AJ026TNLPEG/EU, AJ035TNLPEG/EU
230 356 100
AJ052TNMDEG/EU 233 436 100
7
Console : AJ026TNJDKG/EU, AJ035TNJDKG/EU, AJ052TNJDKG/EU
Unit : mm
B
A
C
Model A B C
AJ026TNJDKG/EU, AJ035TNJDKG/EU,
AJ052TNJDKG/EU
410 320 90
