129
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, DB)
14 16 18 20 21 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2000 3500 5500 138%
-15 2.40 0.74 2.33 0.75 2.26 0.76 2.23 0.76 2.20 0.77 2.15 0.78 2.11 0.78
-10 2.88 0.78 2.80 0.79 2.73 0.80 2.70 0.80 2.67 0.81 2.61 0.82 2.57 0.82
-5 3.36 0.82 3.27 0.83 3.20 0.84 3.16 0.84 3.13 0.85 3.07 0.86 3.02 0.87
0 3.83 0.85 3.75 0.87 3.66 0.88 3.63 0.88 3.59 0.89 3.53 0.90 3.48 0.91
2 4.02 0.87 3.93 0.88 3.85 0.89 3.81 0.90 3.78 0.91 3.71 0.91 3.66 0.92
7 4.41 0.90 4.31 0.91 4.23 0.93 4.20 0.93 4.15 0.94 4.08 0.95 4.02 0.96
10 4.79 0.93 4.69 0.94 4.60 0.96 4.56 0.96 4.52 0.97 4.45 0.98 4.39 0.99
15 5.27 0.97 5.17 0.98 5.08 1.00 5.03 1.00 4.99 1.01 4.91 1.02 4.85 1.03
2500 2500 5000 125%
-15 2.40 0.75 2.33 0.76 2.26 0.77 2.23 0.77 2.20 0.78 2.15 0.78 2.11 0.79
-10 2.88 0.79 2.80 0.80 2.73 0.81 2.70 0.81 2.67 0.82 2.61 0.83 2.57 0.83
-5 3.36 0.83 3.27 0.84 3.20 0.85 3.16 0.85 3.13 0.86 3.07 0.87 3.02 0.87
0 3.83 0.86 3.75 0.88 3.66 0.89 3.63 0.89 3.59 0.90 3.53 0.91 3.48 0.92
2 4.02 0.88 3.93 0.89 3.85 0.90 3.81 0.91 3.78 0.91 3.71 0.92 3.66 0.93
7 4.41 0.91 4.31 0.92 4.23 0.94 4.20 0.94 4.15 0.95 4.08 0.96 4.02 0.97
10 4.79 0.94 4.69 0.95 4.60 0.97 4.56 0.97 4.52 0.98 4.45 0.99 4.39 1.00
15 5.27 0.98 5.17 0.99 5.08 1.01 5.03 1.01 4.99 1.02 4.91 1.03 4.85 1.04
2500 3500 6000 150%
-15 2.40 0.76 2.33 0.77 2.26 0.78 2.23 0.78 2.20 0.79 2.15 0.79 2.11 0.80
-10 2.88 0.79 2.80 0.81 2.73 0.82 2.70 0.82 2.67 0.83 2.61 0.83 2.57 0.84
-5 3.36 0.83 3.27 0.85 3.20 0.86 3.16 0.86 3.13 0.87 3.07 0.88 3.02 0.88
0 3.83 0.87 3.75 0.89 3.66 0.90 3.63 0.90 3.59 0.91 3.53 0.92 3.48 0.93
2 4.02 0.89 3.93 0.90 3.85 0.91 3.81 0.92 3.78 0.92 3.71 0.93 3.66 0.94
7 4.41 0.92 4.31 0.93 4.23 0.95 4.20 0.95 4.15 0.96 4.08 0.97 4.02 0.98
10 4.79 0.95 4.69 0.96 4.60 0.98 4.56 0.98 4.52 0.99 4.45 1.00 4.39 1.01
15 5.27 0.99 5.17 1.00 5.08 1.02
5.03 1.02 4.99 1.03 4.91 1.04 4.85 1.05
NOTE
 The performance table shows the average value of each conditions.
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU
 The total ability of connected a indoor unit is up to 6.0kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
