5. Dimensional Drawing
5-2. Indoor unit
3
AR4500 : AR18TXHZAWKNEU, AR24TXHZAWKNEU
AR5500 : AR18TXFYAWKNEU, AR24TXFYAWKNEU
AR9500 : AR18TXFCAWKNEU, AR24TXFCAWKNEU, AR18TXEAAWKNEU, AR24TXEAAWKNEU
Units : mm [inches]
[41-1/2]1054.5
[11-3/4]299.0
[21-1/8]537.0
[20-3/8]
517.5
[2-7/16]61.5
[2-9/16]65.0
[2-9/16]65.0
[24-7/8]631.5
[3-5/16]84.0
[1-1/8]29.0
[2-1/2]64.0[2-1/2]64.0[6-15/16]175.6
[1-1/8]29.0
[41-1/2]1054.5
[8-7/16]215
[11-3/4]299
[2-9/16]65.0
[2-5/16]58.1
[2-7/16]62.4
