Samsung AR12TXCAAWKNEU - Page 65

65
5. Dimensional Drawing
5-2. Indoor unit
2
AR9500 : AR07TXEAAWKNEU, AR09TXEAAWKNEU, AR12TXEAAWKNEU
AR07TXCAAWKNEU, AR09TXCAAWKNEU, AR12TXCAAWKNEU
Units : mm [inches]
[35] 889.0
[11-3/4]
299.0
[2-9/16]
65.0
[9-5/8] 245.0
[1-1/8]
29.0
[3-5/16] 84.0
[1-1/8]
29.0
[35] 889.0
[2-1/2]
57.9
[2-9/16]
65.2
[11-3/4]
299
[8-7/16] 215
[1-7/8] 48.3
[2-9/16]
65.0
[16-5/8] 422.4
[2-7/16]
61.5
[2-1/2] 64.0
[15-5/8] 397.0
[2-1/2] 64.0
466.6
