5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 C409 2203-000292 C-CER,CHIP;0.01nF,5%,50V,C0G,1608 2 SA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 SNA
....4 DC108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 25 SC
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 2 SNA
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 18 SC
....4 X202 2801-003773
CRYSTAL-SMD;12MHz,30ppm,28-
AAN,20pF,50oh
1 SA
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 2 SNA
....4 AC510 3708-001150
CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-
A,SN,Y
1 SA
....4 3711-005743
HEADER-BOARD TO
CABLE;BOX,5P,1R,1.25mm,A
1 SA
....4 T0077 BN41-01310A PCB MAIN;PLUM B2230N,CEM-3,2,MP1.0,1.6,5 1 SNA
....4 T0527 BN68-00931A
LABEL;ALL,S.MARINA,PREMIUM TRANSFER,T
0.
1 SNA
....4 M0018 BN97-03932H ASSY MICOM;B2030N 1 SNA
.....5 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8,S 1 SNA
....4 0402-001614 DIODE-RECTIFIER;S1G,400V,1A,DO-214AC,TP 1 SA
....4 L2011 3301-001145
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82o
hm
4 SNA
....4 T0087 1203-006118 IC-POSI.FIXED REG.;S-1172B18-U5T1G,SOT-8 1 SA
....4 T0087 1203-006141 IC-POSI.FIXED REG.;S-1172B33-U5T1G,SOT-8 1 SA
....4 6MC22 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 6 SNA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 SNA
..2 M0006 BN96-12500B ASSY SHIELD P-COVER;PLUM 20 analog,SECC, 1 SNA
...3 BN61-05973A STUD-PEM;PLUM23'',M4,D8,L20 2 SNA
...3 M0107 BN63-06352B SHIELD-COVER;PLUM 20 analog,SECC,T0.8 1 SNA
...3 M0131 BN63-00049A GASKET;RB17AS,Conductive Fabric,1.5MM,10 1 SNA
...3 M0131 BN63-03474A GASKET;HUBBLE 27",Polyurethane+Polyester 4 SNA
..2 T0081 6001-002408
SCREW-MACHINE;BH,+,WT,M4,L12,ZPC(WHT
),SW
2 SA
..2 M0214 BN96-02854W
ASSY CABLE P-FLAT CABLE;MCKINLEY,FLAT
CA
1 SA
..2 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
0.1 BN91-04672A ASSY SHIELD;B2030 1 SNA
..2 CIS1 0203-001598 TAPE-FILAMENT;#8915,0.15,12,55000,CLR 0.24 SNA
0.1 BN92-05472M ASSY BOX;LS20PUYKF/EN 1 SNA
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 1 SNA
..2 BH68-00656A
LABEL BOX-00;ALL MODEL,MOJO
90G,90,95,WH
1 SNA
..2 BN69-04365A BOX-02,SET;B2030,CB,A-01,SW2, ECT 40,YEL 1 SNA
0.1 BN92-05473A ASSY P/MATERIAL;LS20PUZKFV/ZC 1 SNA
..2 S.N.A 0203-001100
TAPE-OPP MASKING;OPP/W75/
CLR,T0.075,W75,
1.41 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 T0524 6902-000241 BAG PE;HDPE/NITRON,T0.5/T0.012,W600,L600 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 2.04 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
..2 T0527 BH68-40364A
LABEL-SUMMARY;G52,G72,ART,100G,WHT,BL
K,W
1 SNA
..2 BH69-00457C PACKING INNER-00,PAD;COMM,T3.0,880,1320, 1 SNA
..2 T0527 BN68-00129A LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP 1 SNA
..2 BN69-00391P PAD-ANGLE;T4,50,2200,YEL,56g 1 SNA
