Parts No. Description / Specification Q'ty Remarks
0401-001002 DIODE-SWITCHING;1N4148M,100V,200mA,500mW 16 D4~19
0402-000559 DIODE-RECTIFIER;D4G,400V,1A,T-1 3 D1~3
0403-000387 DIODE-ZENER;UZP24B,24V,22.8-25.6V,1W,DO- 1 ZD04
0501-000283 TR-SMALL SIGNAL;KSA539-Y,PNP,400mW,TO-92 1 TR01
0501-000388 TR-SMALL SIGNAL;KSC815-Y,NPN,400mW,TO-92 1 TR03
0504-001014 TR-DIGITAL;KSR1005,NPN,300mW,4.7K-10K,TO 6 TR2,4~8
0504-001015 TR-DIGITAL;KSR2005,PNP,300mW,4.7K-10K,TO 1 TR09
2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4 2 R1,2
2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m 1 R16
2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 6 R12~14,19~21
2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 8 R5,6,8~10,18,22,23
2001-000435 R-CARBON;1Mohm,5%,1/8W,AA,TP,1.8x3.2mm 1 R07
2001-000613 R-CARBON;3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m 7 R11,15,17,24~27
2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 2 R3,4
2011-001072 R-NETWORK;47Kohm,5%,1/8W,A,SIP,6P,TP 1 AR01
2202-000780 C-CERAMIC,MLC-AXIAL;UP050F104Z 100NF,+80 5 C5,6,9,10,19
2202-000796 C-CERAMIC,MLC-AXIAL;UP050B102KB 1NF,10%, 4 C11~14
2401-000247 C-AL;1SA1ANB107MAN 100UF,20%,10V,GP 6.3X 1 C03
2401-000914 C-AL;CESSL1C220M0511AA 22UF,20%,16V,GP 5 1 C04
2401-001412 C-AL;1SG1VFB477MAN 470UF,20%,35V,GP 10X1 1 C01
2802-000143 RESONATOR-CERAMIC;KBR-4.19M 4.19MHZ,0.5% 1 XTL1
3501-001014 RELAY-POWER;OM1F-S-124LM 24V,21.8MA,17A 1 RY01
3501-001015 RELAY-POWER;OZF-S-124LM1P 24V,21.8MA,16A 1 RY04
3501-001016 RELAY-MINIATURE;JV24-KT 24V,12.5MA,5A 1F 1 RY02
3501-001016 RELAY-MINIATURE;JV24-KT 24V,12.5MA,5A 1F 1 RY03
3708-000528 CONNECTOR-FPC/FC/PIC;FCZ254-13SL,BLK 13P 1 CN04
3711-000203 CONNECTOR-HEADER;YW396-03AV WHT STRAIGHT 1 CN01
3711-000240 CONNECTOR-HEADER;1WALL,4P,1R,3.96mm,STRA 1 CN02
3711-000881 CONNECTOR-HEADER;SMW250-03,WHT BOX,3P,1R 1 CN03
71607-402-290 C-ELEC;04W 50V 100UF (TAPG) 1 C02
A1100-1049 C-CERAMIC;CC OA CH 50V T 220-J 3.5X1.9 U 2 C7,8
A4106-0154 DIODE-ZENER;TZP5.1B 5.1/5.7V 40MA T 1W 3 ZD1~3
DE07-10081A V.F.DISPLAY;SVM-4SM03 GRN/RSHORG 4 51 81 1 VFD1
DE09-30509A IC-MCU;HD404316-C16S DIP CE945G/CE745G(E 1 IC01
DE13-20009A IC;KA7533 DIP 1 IC02
DE26-20141A TRANS-L.V;SLV-945E 230V 50HZ AC17/2.9V 1 LVT1
DE30-20016A BUZZER;CBE2220BA STICK 1 BUZ1
DE39-60001A WIRE-SO COPPER;PI0.6 SN T 52MM TAPING_WI 25 J1~25
DE41-10361A P.C.B-MAIN;FR-1 T1.6 W88 L163 EU2(M945) 1
DE60-60012A PIN-EYELET;ID2.1 OD2.5 L3.0 SN BSP T0.25 8 E1~8
DE61-90004A HOLDER-DIGITRON;NYLON#66 1.5 85 36 8GR B 1
