RB10 183.5 144.5 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
RB11 181 136.5 2001-000053 REF-CF,3.3K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RB12 165.5 133 2001-000224 REF-CF,1.2M,5%,1/6W 150V,-1300 TO +350PPM/C,1.9X3.2
RB13 172.5 124 2001-000367 REF-CF,15K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RB14 159 127 2001-000963 REF-CF,75K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RB15 198.8 90.6 2001-000086 REF-CF,100K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RB17 49.2 46.7 2002-000142 R-COMPOSITION 39ohm,10%,1/2W,AA,TP,3.5x9.5mm
RB18 139 81.6 2001-000077 REF-CF,47K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG01 106.5 65.5 2001-000026 REF-CF,75,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG02 109 65.6 2001-000026 REF-CF,75,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG04 111.2 114.1 2001-000039 R-CARBON 390ohm,5%,1/6W,AA,TP,1.8x3.2mm
RG05 108.5 107 2001-000301 REF-CF,10,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG06 71 120 2001-000935 R-CARBON 68ohm,5%,1/4W,AA,TP,2.4x6.4mm
RG07 64.5 142 2001-000089 REF-CF,150K,5%,1/6W 150KOHM,5%,1/6W,AA,TP,1.8X3.2MM
RG08 190.9 144.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG09 196.5 130.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG10 187 113.5 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
RG11 189.5 121.5 2001-000053 REF-CF,3.3K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG12 169 141 2001-000224 REF-CF,1.2M,5%,1/6W 150V,-1300 TO +350PPM/C,1.9X3.2
RG13 194.5 113.5 2001-000367 REF-CF,15K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG14 192 121.5 2001-000963 REF-CF,75K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG15 196.3 90.6 2001-000086 REF-CF,100K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG17 15 56.9 2002-000142 R-COMPOSITION 39ohm,10%,1/2W,AA,TP,3.5x9.5mm
RG18 141.7 81.6 2001-000077 REF-CF,47K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RG19 108.3 120.6 2001-000086 REF-CF,100K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR01 119 65.5 2001-000026 REF-CF,75,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR02 116.6 65.5 2001-000026 REF-CF,75,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR04 119 115.1 2001-000039 R-CARBON 390ohm,5%,1/6W,AA,TP,1.8x3.2mm
RR05 116.4 107.1 2001-000301 REF-CF,10,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR06 64 120 2001-000935 R-CARBON 68ohm,5%,1/4W,AA,TP,2.4x6.4mm
RR07 52 142 2001-000089 REF-CF,150K,5%,1/6W 150KOHM,5%,1/6W,AA,TP,1.8X3.2MM
RR08 171.5 140.3 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR09 193.5 144 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR10 188.5 144.5 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
RR11 186 136.5 2001-000053 REF-CF,3.3K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR12 198.5 144 2001-000224 REF-CF,1.2M,5%,1/6W 150V,-1300 TO +350PPM/C,1.9X3.2
RR13 205.8 133.5 2001-000367 REF-CF,15K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR14 196 136 2001-000963 REF-CF,75K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR15 193.8 90.6 2001-000086 REF-CF,100K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
RR17 30.6 16.8 2002-000142 R-COMPOSITION 39ohm,10%,1/2W,AA,TP,3.5x9.5mm
RR18 144.6 81.6 2001-000077 REF-CF,47K,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
SK1 33.4 53.4 3704-001036 SOCKET-CRT 13P,15.24PI,29PI,NI+SN
SK101 34.3 31.8 4715-000102 SURGE ABSORBER 200V,20%,1000A,RADIAL
SK102 18.4 57 4715-000102 SURGE ABSORBER 200V,20%,1000A,RADIAL
SK103 49.2 50.5 4715-000102 SURGE ABSORBER 200V,20%,1000A,RADIAL
SK104 11.7 50.5 4715-000001 SURGE ABSORBER 1KV,+50-10%
SW1 209 10 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
9 Electrical Parts List
9-16 CKG7507L
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
