Samsung DV5471AEW/XAA User Manual

10 _ Disassembly and Reassembly
Part Figure Description
Duct Exhaust
Removal
1. Disconnectthepowersupplytotheunit.
2. Remove1screwsfromtheBack-Cover.
3. Remove1screwfromtheDuct-Exhaust.
Incasethescrewsforxingapowercodeare
droppedintothedryer,afterremovingDuct
Exhaust,youcanputitoutthroughthehole.
 Reassemblyproceduresareinthereverseorderofdissasemblyprocedures.
