36 _ Troubleshooting

■ Centrifugal Switch (Motor)

■ GAS MODEL

Radiant Sensor(10RS)

• Resistancevalue<1Ω

• Ifresistanceisinnite,replaceRadiantsensor

120V

Igniter(101D)

• Resistancevalue40~400Ω

• Ifresistanceisinnite,replaceIgniter

120V4.5A

Gas Valve(25M01A)

• Valve1-2:Resistancevalue1,365Ω

• Valve1-3:Resistancevalue560Ω

• Valve4-5:Resistancevalue1,325Ω

• Ifresistanceisinnity,replaceValve

120V60Hz,120A

Thermostat (60T21 Hi-Limit)230F-50F

• Resistancevalue<1Ω

• Ifresistanceisinnity,replaceThermostat

120V20A(60T21)

2.88Ωbetween

Pin# 3 and 4

3.5Ωbetween

Pin# 4 and 5
