Troubleshooting _ 37
■ Sensor Bars & temperature sensor check
Sensor Bars
DisconnectharnessandtestPinkwirePin4toOrangewirePin5.
• Approx∞Ωwithoutlaundry
• Approx190Ω±10%withwetclothes
Cycling thermistor
DisconnectharnessandtestBluewirePin3toRedwirePin6.
• Approx10KΩat25°C/77°F
CN6
6 1
复件 Hudson_Dryer_SM_E.indb 37 2012-4-2 15:20:58
