English 25
Installation
Figure 5
Elbow (
Elbow (
3
/ 4
" (9.5 mm))
" (9.5 mm))
Power cable
Power cable
Side gasket
Side gasket
1 inch
1 inch
Side gasket
Side gasket
Drain hose
Drain hose
Hot Water Supply Line
Hot Water Supply Line
Junction box
Junction box
built-in hook
built-in hook
Hot Water Supply Line
Hot Water Supply Line
Inlet valve
Inlet valve
CAUTION
Do not overtighten the 90° Fitting.
Doing so may damage the water inlet valve and cause a water leak.
Make sure the dishwasher is positioned to the center.
