English 33
Installation
Figure 9
If necessary, cut off the dotted line of the
If necessary, cut off the dotted line of the
drain hose to t the size.
drain hose to t the size.
1 in.
1 in.
(25 mm)
(25 mm)
7
7
/
/
8
8
in.
in.
(22 mm)
(22 mm)
5
5
/
/
8
8
in.
in.
(16 mm)
(16 mm)
Figure 10
Drain hose
Drain hose
Dishwasher
Dishwasher
Sink
Sink
Min. 10 in.
Min. 10 in.
(254 mm)
(254 mm)
To prevent backow for models without
the air gap, secure the drain hose to the
side wall of the kitchen cabinet using cable
ties or other xtures. Make sure the drain
hose is high at least 10 inches from the
sink connector.
