Samsung E1720NR - Page 11

5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 CER04 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
....4 MROP1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 14 SA
....4 AR108 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 5 SA
....4 ARR2 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 2 SA
....4 ZR24 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 SNA
....4 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 3 SNA
....4 HR13 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 SNA
....4 ZR10 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 3 SNA
....4 R1 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608 6 SNA
....4 C134 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 SA
....4 C409 2203-000292 C-CER,CHIP;0.01nF,5%,50V,C0G,1608 2 SA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 SNA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 SNA
....4 6MC22 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 6 SNA
....4 DC108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 24 SC
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 2 SNA
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 19 SC
....4 X202 2801-003773
CRYSTAL-SMD;12MHz,30ppm,28-
AAN,20pF,50oh
1 SA
....4 L2011 3301-001145
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82o
hm
4 SNA
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 2 SNA
....4 AC510 3708-001150
CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-
A,SN,Y
1 SA
....4 HB01A 3711-005743
HEADER-BOARD TO
CABLE;BOX,5P,1R,1.25mm,A
1 SA
....4 T0077 BN41-01323A PCB MAIN;PLUM B1630N,CEM-3,2,MP1.0,1.6,5 1 SNA
....4 BN97-04136D ASSY MICOM;E1920N,STZ,BN94-03250* 1 SNA
.....5 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8,S 1 SNA
..2 M0006 BN96-12503C ASSY SHIELD P-COVER;PLUM 18.5",SECC,T0.8 1 SNA
...3 BN61-05973A STUD-PEM;PLUM23'',M4,D8,L20 2 SNA
...3 M0107 BN63-06355C SHIELD-COVER;PLUM 18.5",SECC,T0.8,18.5" 1 SNA
...3 T0073 AA63-01141A GASKET-EMI;42D5,Conductive Fabric,1.5mm, 2 SNA
...3 M0131 BN63-00049A GASKET;RB17AS,Conductive Fabric,1.5MM,10 3 SNA
...3 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 1 SNA
..2 T0081 6001-002408
SCREW-MACHINE;BH,+,WT,M4,L12,ZPC(WHT
),SW
2 SA
..2 M0081 6003-000264
SCREW-TAPTYPE;PWH,+,-
,B,M3,L6,ZPC(WHT),S
2 SA
..2 M0214 BN96-02854W
ASSY CABLE P-FLAT CABLE;MCKINLEY,FLAT
CA
1 SA
0.1 BN91-05285A ASSY SHIELD;E1920 1 SNA
..2 CIS1 BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915, 0.3 SNA
0.1 BN92-05486D ASSY LABEL;Cobalt, BLACK 1 SNA
..2 CCM1 BN68-01570A LABEL RATING;ALL,SS,PE,T0.05,90,45,Dark 1 SNA
0.1 BN92-05547L ASSY P/MATERIAL;S19S3,W/W 1 SNA
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 1.31 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 T0524 6902-000241 BAG PE;HDPE/NITRON,T0.5/T0.012,W600,L600 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.5 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
..2 AA69-00243G PAD-PLATE;CB SW-2,YEL,990,990,-,-,SP43J5 1 SNA
