Samsung HW-S60B Full Manual

ENG - 30
06 CONNECTING AN EXTERNAL DEVICE
Connecting using an Optical Cable
LED
Indicator
White On -> Off
“Digital Audio In”
- AUDIO -
R L
OPTICAL OUT
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
Bottom of the Soundbar
Optical Cable
(not supplied)
Top of the Soundbar
BD / DVD player / Set-top
box / Game console
1. With the external device and Soundbar turned off, connect the DIGITAL AUDIO IN (OPTICAL) port
on the Soundbar and the OPTICAL output port on the external device with the optical cable (not
supplied), as shown in the gure.
2. Turn on the Soundbar and external device.
3. Press the (Multi Function) button at the top of the Soundbar or the (Source) button on the
remote control and then select the “Digital Audio In” mode. Then the announcement, “Digital
Audio In” is output.
4. The external device sound is output from the Soundbar.

Samsung HW-S60B Specifications

General

Audio decoders	DTS 5.1, Dolby Atmos, Dolby Digital Plus
RMS rated power	200 W
Audio output channels	5.0 channels
Soundbar mode control	Yes
Number of woofer drivers	4
Number of tweeter drivers	3
Subwoofer included	-
Product color	Black
Virtual assistant	Amazon Alexa
USB direct playback	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Sustainability certificates	ENERGY STAR
Bluetooth codec	SBC
Wi-Fi frequency	5 GHz
Connectivity technology	Wired & Wireless
Package depth	157.48 mm
Package width	906.78 mm
Package height	124.46 mm
Package weight	4082 g
Cables included	AC, HDMI
Number of products included	1 pc(s)

Weight and Dimensions

Depth	105 mm
Width	670 mm
Height	62 mm
Soundbar weight	2700 g
