4. Frame 설치 및 케이블 연결
Fig.1 Check the operation
after installing one
Fig.2 Check the operation
after installing two
⑩ Check the operation of each ASSY BRACKET P-FRONT installation.
- Connect the power of the SET power cord to check whether the entire LED is damaged or not and check the output.
Fig.3 Check the operation
after installing three
