5-409
5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
..2 M2893 BN39-01099B LEAD CONNECTOR;LN55A950D1FXZA,UL1007#26, 1 S.A
..2 M0174 BN44-00287A IP BOARD;IP-361609F,I52F2_9SS,146mA,166m 1 S.A
..2 M0115 BN61-04788A BRACKET-STAND LINK;46, B610,SECC,T2.0 1 S.N.A
..2 M0254 BN61-04800A HOLDER-SIDE AV;EO,ABS+PMMA,HB,BK23,H/GLO 1 S.N.A
...3 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 17.3 S.N.A
..2 T0101 BN61-04817A BRACKET-WALL;46, B610,SECC,T1.6 4 S.N.A
..2 M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 4 S.N.A
..2 BN63-05259A COVER-MAIN;EO,ABS+PMMA,HB,BK23,H/GLOSSY 1 S.N.A
...3 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.015 S.N.A
..2 M0230 BN96-10074A ASSY CABLE P-FPCB LVDS;LA46A650A1,FPCB L 1 S.A
..2 T0081 6001-002284 SCREW-MACHINE;BH,+,M4,L8,ZPC(WHT),SWRCH1 6 S.A
..2 T0081 6001-002284 SCREW-MACHINE;BH,+,M4,L8,ZPC(WHT),SWRCH1 6 S.A
0.1 M0019 BN92-04476B ASSY LABEL;LE46B750U1WXXC 1 S.N.A
0.1 M0045 BN92-04477C ASSY ACCESSORY;LE52B750U1WXXC 1 S.N.A
..2 M0045 BN96-10041A ASSY ACCESSORY-MANUAL;LE40B750U1WXXC 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,-,9 1 S.N.A
...3 AA68-03242Q MANUAL FLYER-02,SAFETY GUIDE;comm,Samsun 1 S.N.A
...3 T0076 BN68-00514E MANUAL FLYER-02,WARRANTY CARD;comm,Samsu 1 S.N.A
...3 BN68-00907D MANUAL FLYER-WEEE BATTERY;COMM,SAMSUNG,2 1 S.N.A
...3 BN68-02004A MANUAL FLYER-QSG;B750,SAMSUNG,9Langs,W.E 1 S.N.A
...3 BN96-10411A ASSY MANUAL P-USB;B750,USB,SAMSUNG,W.EUR 1 S.N.A
....4 BN59-00893A S/W DRIVER-USB;HANIL 512,E-manual,HANIL, 1 S.N.A
...3 BN59-00726D S/W DRIVER-CD;LN40B650T1F,DLNA,WorldWide 1 S.N.A
..2 M0045 BN96-10041D ASSY ACCESSORY-CABEL;LE52B750U1WXXC 1 S.A
...3 T0268 3903-000145 CBF-POWER CORD;DT,EU,FP3/YES,U(IEC C13-R 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,-,9 1 S.N.A
...3 T0074 BN59-00860A REMOCON;LCD850,750,TM970,EUROPE,49 1 S.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05314B COVER-BOTTOM;52,LB620,HIPS,HB,BK500 1 S.A
....4 BN81-00199H RESIN;HIPS HB,BK500,HF-1690H,K2901 81.4 S.N.A
...3 M0560 BN96-01800A ASSY ACCESSORY-SCREW ZIPPER;ROME32,-,-,- 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
....4 ACCESSORY 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,-,-,4- 1 S.N.A
...3 BN61-05596A HOLDER-WIRE CABLE;LED TV,LDPE,T1.1,L150, 1 S.N.A
0.1 M0113 BN92-04784A ASSY P/MATERIAL;52,LB750 1 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 5 S.N.A
..2 T0524 6902-001042 BAG PE;HDPE/NITRON,T0.015/T0.5,W1500,L10 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.76 S.N.A
0.1 M0003 BN92-04787B ASSY BOX;52,LB750,EO 1 S.N.A
..2 M0521 BN69-03481A BOX-SET,IN;52LB610,CB,C-01,DW1(DY-01),YE 1 S.N.A
..2 BN69-03611B BOX-SET,OUT;52LB750-S,CB,DW3,YEL,W1547,D 1 S.N.A
