5. Exploded View & Part List
5-3-1. LE40B55* Parts List
Location No. Code No. Description & Specifi cation Q’ty S.A/S.N.A Remark
T0003 BN96-09555B ASSY COVER P-FRONT;40,LB550,EO,PC(CLR)+P 1 S.A
M0215
BN07-00675D LCD-PANEL;LTF400HA08 1 S.A
BN81-02390A A/S-T CON V400H1-L05;V400H1-L05 1 S.A
T0175 BN96-09463C ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:60 1 S.A
M0115 BN61-04918A BRACKET-STAND LINK;40, B610,SECC,T1.6 1 S.N.A
M0146 BN61-03414A BRACKET-PANEL TOP;B650-32,SECC,T1.2 2 S.N.A
M0174 BN44-00264C IP BOARD;H40F1_9HS,H40F1_9HS,0.11mA,11mA 1 S.A
M0014 BN94-02668C ASSY PCB MAIN;LE40B550A5WXXC 1 S.A
M0254 BN61-04801C HOLDER-SIDE AV;EO,HIPS,HB,BK500,1USB,1HD 1 S.N.A
T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.N.A
M0013 BN96-09613A ASSY COVER P-REAR;40,LB550,EO,HIPS,HB,BK 1 S.A
M0027 BN96-09610A ASSY STAND P-BASE;40,LB610,TEMPERED GLAS 1 S.A
