5. Exploded View & Part List
5-9-1. LE55B65* Parts List
Location No. Code No. Description & Specifi cation Q’ty S.A/S.N.A Remark
T0003 BN96-09491B ASSY COVER P-FRONT;55,LB650,EO,PC(CLR)+P 1 S.A
M0215 BN07-00695A LCD-PANEL;V546H1-L01 1 S.A
M0215 BN81-02395A A/S-T CON V546H1-LH1;V546H1-LH1 1 S.A
T0175 BN96-09466A ASSY SPEAKER P;8ohm,4pin,15W,R:800 / L:8 1 S.A
M0115 BN61-04788A BRACKET-STAND LINK;46, B610,SECC,T2.0 1 S.N.A
M0174 BN44-00268A IP BOARD-IP;I55F2_9HS,I55F2_9HS,5.5mA,6. 1 S.A
T0101 BN61-04817A BRACKET-WALL;46, B610,SECC,T1.6 4 S.N.A
M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 5 S.N.A
M0014 BN94-02583E ASSY PCB MAIN;LE55B653T5WXXC 1 S.A
M0254 BN61-04800A HOLDER-SIDE AV;EO,ABS+PMMA,HB,BK23,H/GLO 1 S.N.A
M0013 BN96-09510A ASSY COVER P-REAR;55,LB650,EO,ABS+PMMA,H 1 S.N.A
M0027 BN96-10606A ASSY STAND P-BASE;55,LB650,TEMPERED GLAS 1 S.N.A
